Sony HCD-GPX33 - DC Fan, CDM90 Bracket Section

58
HCD-GPX33/GPX55/GPX77/GPX88
51 2-677-839-01 +PWH 3X8 (SUMITITE)
0 52 1-855-006-41 FAN, DC
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark
7-2. DC FAN, CDM90 BRACKET SECTION
A
A
B
C
C
#2
#2
#2
#2
#2
#2
#2
(GPX88)
(GPX88)
front panel
section
chassis section
not supplied
CD MECHANISM section
52
51
D
#2
not supplied
D
B
