Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
63
HCD-GPX9
BDAMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
R553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R555 1-216-864-11 SHORT CHIP 0
R556 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R557 1-216-842-11 METAL CHIP 56K 5% 1/10W
R558 1-216-821-11 METAL CHIP 1K 5% 1/10W
R559 1-216-835-11 METAL CHIP 15K 5% 1/10W
0 R560 1-220-755-11 METAL 0.22 10% 2W F
R561 1-216-845-11 METAL CHIP 100K 5% 1/10W
R562 1-260-076-11 CARBON 10 5% 1/2W
R563 1-216-842-11 METAL CHIP 56K 5% 1/10W
0 R564 1-215-890-11 METAL OXIDE 470 5% 2W F
R565 1-216-845-11 METAL CHIP 100K 5% 1/10W
R601 1-216-833-11 METAL CHIP 10K 5% 1/10W
R602 1-216-849-11 METAL CHIP 220K 5% 1/10W
R603 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R604 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R605 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R606 1-202-972-61 FUSIBLE 1 5% 1/4W F
0 R607 1-202-972-61 FUSIBLE 1 5% 1/4W F
0 R608 1-212-881-11 FUSIBLE 100 5% 1/4W F
R609 1-216-833-11 METAL CHIP 10K 5% 1/10W
R610 1-216-839-11 METAL CHIP 33K 5% 1/10W
R611 1-216-833-11 METAL CHIP 10K 5% 1/10W
R612 1-216-845-11 METAL CHIP 100K 5% 1/10W
R613 1-216-833-11 METAL CHIP 10K 5% 1/10W
R614 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R615 1-215-890-11 METAL OXIDE 470 5% 2W F
R619 1-216-821-11 METAL CHIP 1K 5% 1/10W
R620 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R621 1-216-845-11 METAL CHIP 100K 5% 1/10W
R622 1-216-837-11 METAL CHIP 22K 5% 1/10W
R624 1-216-821-11 METAL CHIP 1K 5% 1/10W
R625 1-216-809-11 METAL CHIP 100 5% 1/10W
R626 1-216-809-11 METAL CHIP 100 5% 1/10W
R628 1-216-853-11 METAL CHIP 470K 5% 1/10W
************************************************************
A-4750-181-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C10 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C11 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C14 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C15 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C16 1-115-156-11 CERAMIC CHIP 1uF 10V
C17 1-126-934-11 ELECT 220uF 20% 16V
C18 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C111 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C112 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C113 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C114 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C115 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C116 1-126-934-11 ELECT 220uF 20% 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C122 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C125 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C132 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C141 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C142 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C143 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C151 1-126-934-11 ELECT 220uF 20% 16V
C160 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C161 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C162 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C163 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C164 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C170 1-126-934-11 ELECT 220uF 20% 16V
C171 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C172 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C174 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C181 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C182 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C183 1-126-934-11 ELECT 220uF 20% 16V
C184 1-126-934-11 ELECT 220uF 20% 16V
C185 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C186 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C194 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C195 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C201 1-126-934-11 ELECT 220uF 20% 16V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C203 1-126-934-11 ELECT 220uF 20% 16V
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C212 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C213 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C251 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C252 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C257 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C258 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C259 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN101 1-793-907-11 CONNECTOR, FFC/FPC 16P
CN201 1-568-860-11 SOCKET, CONNECTOR 17P
< IC >
IC101 8-752-425-11 IC CXD3058AR
IC251 6-705-808-01 IC BA5947FM-E2
< JUMPER RESISTOR >
JR101 1-216-296-11 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR103 1-216-296-11 SHORT CHIP 0
JR104 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-296-11 SHORT CHIP 0
JR107 1-216-296-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
