– 16 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TCB
C1713 1-130-736-11 PP FILM 0.01uF 5% 16V
C1714 1-126-960-11 ELECT 1.0uF 20% 50V
C1715 1-126-960-11 ELECT 1.0uF 20% 50V
C1716 1-126-960-11 ELECT 1.0uF 20% 50V
C1719 1-126-967-11 ELECT 47uF 20% 16V
C1720 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1723 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1724 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1725 1-126-967-11 ELECT 47uF 20% 16V
C1726 1-126-960-11 ELECT 1.0uF 20% 50V
C1727 1-126-960-11 ELECT 1.0uF 20% 50V
C1728 1-126-966-11 ELECT 33uF 20% 16V
< FILTER >
CF1 1-567-389-11 FILTER, CERAMIC
CF3 1-567-389-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< TRIMMER >
CT1701 1-141-444-11 CAP, CERAMIC TRIMMER 50PF
< DIODE >
D21 8-719-976-99 DIODE UDZ-TE-17-5.1B
D41 8-719-016-74 DIODE 1SS352-TPH3
D42 8-719-016-74 DIODE 1SS352-TPH3
D43 8-719-016-74 DIODE 1SS352-TPH3
D1701 8-719-016-74 DIODE 1SS352-TPH3
D1702 8-719-016-74 DIODE 1SS352-TPH3
D1703 8-719-987-63 DIODE 1N4148M-TA
D1704 8-719-016-74 DIODE 1SS352-TPH3
< FRONTEND >
FE1 1-693-335-11 FRONT END (3 GANG)
FE2 1-233-514-11 ENCAPSULATED COMPONENT
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
IC1701 8-759-063-04 IC IR3R42
IC1702 8-759-140-53 IC MC14053BCP
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< CHIP CONDUCTOR >
JR2 1-216-295-91 CONDUCTOR, CHIP (2012)
JR6 1-216-295-91 CONDUCTOR, CHIP (2012)
JR8 1-216-295-91 CONDUCTOR, CHIP (2012)
JR9 1-216-295-91 CONDUCTOR, CHIP (2012)
JR46 1-216-296-91 CONDUCTOR, CHIP (3216)
JR47 1-216-295-91 CONDUCTOR, CHIP (2012)
JR48 1-216-295-91 CONDUCTOR, CHIP (2012)
JR49 1-216-296-91 CONDUCTOR, CHIP (3216)
JR51 1-216-295-91 CONDUCTOR, CHIP (2012)
JR52 1-216-295-91 CONDUCTOR, CHIP (2012)
JR53 1-216-296-91 CONDUCTOR, CHIP (3216)
JR54 1-216-295-91 CONDUCTOR, CHIP (2012)
JR1701 1-216-295-91 CONDUCTOR, CHIP (2012)
JR1702 1-216-295-91 CONDUCTOR, CHIP (2012)
JR1703 1-216-295-91 CONDUCTOR, CHIP (2012)
JR1704 1-216-295-91 CONDUCTOR, CHIP (2012)
JR1705 1-216-295-91 CONDUCTOR, CHIP (2012)
< COIL >
L3 1-410-521-11 INDUCTOR, MICRO 100uH
L41 1-407-500-00 MICRO INDUCTOR 4.7mH
L1701 1-409-497-11 COIL (FILTER)
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q5 8-729-424-08 TRANSISTOR MUN2111T1
Q9 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q11 8-729-421-22 TRANSISTOR MUN2211T1
Q12 8-729-421-22 TRANSISTOR MUN2211T1
Q13 8-729-421-22 TRANSISTOR MUN2211T1
Q14 8-729-421-22 TRANSISTOR MUN2211T1
Q1701 8-729-424-08 TRANSISTOR MUN2111T1
Q1702 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q1703 8-729-421-22 TRANSISTOR MUN2211T1
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
