– 17 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-249-417-11 CARBON 1K 5% 1/4W
R22 1-249-417-11 CARBON 1K 5% 1/4W
R23 1-249-417-11 CARBON 1K 5% 1/4W
R24 1-216-025-91 CHIP (2012) 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 CHIP (3216) 330 5% 1/8W
R31 1-216-025-91 CHIP (2012) 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W
R33 1-249-425-11 CARBON 4.7K 5% 1/4W
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 CHIP (3216) 4.7K 5% 1/8W
R36 1-216-025-91 CHIP (2012) 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 CHIP (2012) 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-216-073-00 METAL CHIP 10K 5% 1/10W
R43 1-216-042-00 METAL CHIP 510 5% 1/10W
R44 1-216-013-00 METAL CHIP 33 5% 1/10W
R45 1-247-843-11 CARBON (SMALL) 3.3K 5% 1/4W
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
R47 1-216-097-91 CHIP (2012) 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W
R49 1-216-049-91 CHIP (2012) 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R53 1-249-429-11 CARBON 10K 5% 1/4W
R55 1-216-162-00 CHIP (3216) 33 5% 1/8W
R56 1-249-393-11 CARBON 10 5% 1/4W
R91 1-216-295-91 CONDUCTOR, CHIP (2012)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R99 1-249-399-11 CARBON 33 5% 1/4W
R1701 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1702 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1703 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R1704 1-216-076-00 METAL CHIP 13K 5% 1/10W
R1705 1-216-049-91 METAL CHIP 1K 5% 1/10W
R1706 1-216-049-91 METAL CHIP 1K 5% 1/10W
R1707 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1708 1-216-095-00 METAL CHIP 82K 5% 1/10W
R1709 1-216-089-91 METAL CHIP 47K 5% 1/10W
R1710 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1711 1-249-429-11 CARBON 10K 5% 1/4W
R1714 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1715 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1716 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1717 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1718 1-249-429-11 CARBON 10K 5% 1/4W
R1719 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1720 1-249-434-11 CARBON 27K 5% 1/4W
R1721 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV41 1-238-601-11 ADJ, CARBON 22K
RV42 1-238-600-11 ADJ, CARBON 10K
RV1701 1-238-600-11 ADJ, CARBON 10K
RV1702 1-238-599-11 ADJ, CARBON 4.7K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT)(ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-760-220-11 FILTER, CERAMIC
X42 1-527-981-00 FILTER, CERAMIC
X43 1-577-075-11 OSCILLATOR, CERAMIC (456kHz)
************************************************************
TCB
