– 97 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< DIODE >
D619 8-719-058-04 DIODE SEL5223S-TP15 (RIGHT)
D620 8-719-058-04 DIODE SEL5223S-TP15 (RIGHT)
D621 8-719-058-04 DIODE SEL5223S-TP15 (CENTER)
D622 8-719-058-03 DIODE SEL5423E-TP15 (CENTER)
D623 8-719-058-04 DIODE SEL5223S-TP15 (CENTER)
D624 8-719-058-04 DIODE SEL5223S-TP15 (LEFT)
D625 8-719-058-04 DIODE SEL5223S-TP15 (LEFT)
< TRANSISTOR >
Q610 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q611 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R706 1-247-807-31 CARBON 100 5% 1/4W
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R746 1-247-807-31 CARBON 100 5% 1/4W
************************************************************
* A-4392-351-A HP/MIC BOARD, COMPLETE
**********************
(EXCEPT GR7: EA3, EA4, SAF, TH/GR7J)
* A-4392-851-A HP/MIC BOARD, COMPLETE
**********************
(GR7:EA4, SAF, TH)
* A-4392-857-A HP/MIC BOARD, COMPLETE (GR7: EA3/GR7J)
**********************
< CAPACITOR >
C750 1-162-294-31 CERAMIC 0.001uF 10% 50V
C751 1-162-294-31 CERAMIC 0.001uF 10% 50V
C752 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT GR7: EA4, SAF, TH)
C752 1-164-159-21 CERAMIC 0.1uF 50V
(GR7: EA4, SAF, TH)
C753 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT GR7: EA4, SAF, TH)
C753 1-164-159-21 CERAMIC 0.1uF 50V
(GR7: EA4, SAF, TH)
C754 1-162-306-11 CERAMIC 0.01uF 20% 16V
C755 1-126-961-11 ELECT 2.2uF 20% 50V
C756 1-162-294-31 CERAMIC 0.001uF 10% 50V
C757 1-162-215-31 CERAMIC 47PF 5% 50V
C758 1-126-964-11 ELECT 10uF 20% 50V
C759 1-126-959-11 ELECT 0.47uF 20% 50V
C760 1-162-215-31 CERAMIC 47PF 5% 50V
C761 1-162-282-31 CERAMIC 100PF 10% 50V
C762 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-126-964-11 ELECT 10uF 20% 50V
C765 1-126-960-11 ELECT 1uF 20% 50V
(GR7: EA3/GR7J)
C766 1-162-305-11 CERAMIC 0.0068uF20% 16V
(GR7: EA3/GR7J)
C767 1-162-294-31 CERAMIC 0.001uF 10% 50V
(GR7: EA3/GR7J)
C768 1-136-495-11 FILM 0.068uF 5% 50V
(GR7: EA3/GR7J)
C769 1-124-464-11 ELECT 0.22uF 20% 50V
(GR7: EA3/GR7J)
C770 1-124-464-11 ELECT 0.22uF 20% 50V
(GR7: EA3/GR7J)
C771 1-126-967-11 ELECT 47uF 20% 10V
(GR7: EA3/GR7J)
C772 1-164-159-11 CERAMIC 0.1uF 50V
(GR7: EA3/GR7J)
C773 1-104-664-11 ELECT 47uF 20% 25V
(GR7: EA3/GR7J)
C774 1-136-495-11 FILM 0.068uF 5% 50V
(GR7: EA3/GR7J)
C775 1-162-305-11 CERAMIC 0.0068uF20% 16V
(GR7: EA3/GR7J)
C776 1-162-294-31 CERAMIC 0.001uF 10% 50V
(GR7: EA3/GR7J)
C777 1-136-167-00 FILM 0.15uF 5% 50V
(GR7: EA3/GR7J)
C778 1-126-960-11 ELECT 1uF 20% 50V
(GR7: EA3/GR7J)
C779 1-161-494-00 CERAMIC 0.022uF 25V
(GR7: EA3/GR7J)
C780 1-126-961-11 ELECT 2.2uF 20% 50V
(GR7: EA3/GR7J)
C782 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
* CN750 1-568-828-11 SOCKET, CONNECTOR 9P
< DIODE >
D751 8-719-024-99 DIODE 11ES2-NTA2B (GR7: EA3/GR7J)
D752 8-719-024-99 DIODE 11ES2-NTA2B (GR7: EA3/GR7J)
D753 8-719-024-99 DIODE 11ES2-NTA2B (GR7: EA3/GR7J)
< IC >
IC750 8-759-634-51 IC M5218AP
IC751 8-759-450-96 IC M65850P (GR7: EA3/GR7J)
< JACK >
J750 1-569-112-21 JACK, LARGE TYPE (PHONES)
J751 1-569-112-21 JACK, LARGE TYPE (MIX MIC)
HP/MIC
DECO
