Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< COIL >
L751 1-410-521-11 INDUCTOR 100uH (GR7: EA3/GR7J)
< RESISTOR >
R750 1-249-429-11 CARBON 10K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-441-11 CARBON 100K 5% 1/4W
R753 1-249-417-11 CARBON 1K 5% 1/4W
R754 1-247-863-91 CARBON 22K 5% 1/4W
(GR7: EA4, SAF, TH)
R754 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R755 1-249-429-11 CARBON 10K 5% 1/4W
R756 1-247-885-00 CARBON 180K 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
R758 1-249-433-11 CARBON 22K 5% 1/4W
(GR7: EA3/GR7J)
R759 1-249-433-11 CARBON 22K 5% 1/4W
(GR7: EA3/GR7J)
R760 1-249-433-11 CARBON 22K 5% 1/4W
(GR7: EA3/GR7J)
R761 1-247-881-00 CARBON 120K 5% 1/4W
(GR7: EA3/GR7J)
R762 1-249-433-11 CARBON 22K 5% 1/4W
(GR7: EA3/GR7J)
R763 1-249-433-11 CARBON 22K 5% 1/4W
(GR7: EA3/GR7J)
R764 1-249-433-11 CARBON 22K 5% 1/4W
(GR7: EA3/GR7J)
R765 1-249-437-11 CARBON 47K 5% 1/4W
(GR7: EA3/GR7J)
R766 1-249-431-11 CARBON 15K 5% 1/4W
(GR7: EA3/GR7J)
R767 1-249-431-11 CARBON 15K 5% 1/4W
(GR7: EA3/GR7J)
< VARIABLE RESISTOR >
RV750 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV751 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
(GR7: EA3/GR7J)
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-571-281-21 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-572-248-11 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* A-4392-711-A MAIN BOARD, COMPLETE (RX70: CND)
*********************
* A-4392-712-A MAIN BOARD, COMPLETE (RX70: CIS, EE)
*********************
* A-4392-713-A MAIN BOARD, COMPLETE (GR7: E2, MX)
*********************
* A-4392-714-A MAIN BOARD, COMPLETE (GR7: AUS)
*********************
* A-4392-315-A MAIN BOARD, COMPLETE (RX70: US)
*********************
* A-4392-316-A MAIN BOARD, COMPLETE
*********************
(RX70: AEP, AED, G, UK)
* A-4392-317-A MAIN BOARD, COMPLETE
*********************
(GR7: EA3, E3, HK, MY, SP, TW/GR7J)
* A-4392-806-A MAIN BOARD, COMPLETE (D60)
*********************
* A-4392-837-A MAIN BOARD, COMPLETE (GR7: EA4, TH)
*********************
* A-4392-854-A MAIN BOARD, COMPLETE (GR7: SAF)
*********************
* 4-870-539-00 PLATE, GROUND (GR7: EA4, SAF, TH)
* 4-870-539-11 PLATE, GROUND (EXCEPT GR7: EA4, SAF, TH)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
HP/MIC LEAF SWITCH MAIN
