Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
88
HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
R957 1-216-833-11 METAL CHIP 10K 5% 1/10W
R958 1-216-819-11 METAL CHIP 680 5% 1/10W
R960 1-216-819-11 METAL CHIP 680 5% 1/10W
R962 1-216-819-11 METAL CHIP 680 5% 1/10W
R964 1-216-819-11 METAL CHIP 680 5% 1/10W
R965 1-216-835-11 METAL CHIP 15K 5% 1/10W
R966 1-216-835-11 METAL CHIP 15K 5% 1/10W
R968 1-216-837-11 METAL CHIP 22K 5% 1/10W
R969 1-216-839-11 METAL CHIP 33K 5% 1/10W
R970 1-216-843-11 METAL CHIP 68K 5% 1/10W
R971 1-216-833-11 METAL CHIP 10K 5% 1/10W
R973 1-216-819-11 METAL CHIP 680 5% 1/10W
R975 1-216-819-11 METAL CHIP 680 5% 1/10W
R977 1-216-819-11 METAL CHIP 680 5% 1/10W
R979 1-216-819-11 METAL CHIP 680 5% 1/10W
R981 1-216-819-11 METAL CHIP 680 5% 1/10W
R985 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R986 1-216-809-11 METAL CHIP 100 5% 1/10W
R987 1-216-809-11 METAL CHIP 100 5% 1/10W
R988 1-216-809-11 METAL CHIP 100 5% 1/10W
R989 1-216-833-11 METAL CHIP 10K 5% 1/10W
R990 1-216-864-11 SHORT CHIP 0
< SWITCH >
S933 1-771-410-21 SWITCH, TACTILE (SUBWOOFER ON/OFF)
(GTR7/GTR8/GTR8B)
S937 1-771-410-21 SWITCH, TACTILE (SUBWOOFER LEVEL)
(GTR7/GTR8/GTR8B)
S915 1-771-410-21 SWITCH, TACTILE (STOP)
S916 1-771-410-21 SWITCH, TACTILE (EQ BAND/MEMORY)
S917 1-771-410-21 SWITCH, TACTILE (TUNING-(CD))
S918 1-771-410-21 SWITCH, TACTILE (SURR SP MODE(CD))
S919 1-771-410-21 SWITCH, TACTILE (TUNING-(CD))
S920 1-771-410-21 SWITCH, TACTILE (NIGHT MODE)
S921 1-771-410-21 SWITCH, TACTILE (PLAY)
S922 1-771-410-21 SWITCH, TACTILE (SOUND FLASH)
S923 1-771-410-21 SWITCH, TACTILE (ALBUM-(CD))
S924 1-771-410-21 SWITCH, TACTILE (BREAK)
S925 1-771-410-21 SWITCH, TACTILE (RETURN)
S926 1-771-410-21 SWITCH, TACTILE (MP3 BOOSTER + (CD))
S927 1-771-410-21 SWITCH, TACTILE (CD)
S928 1-771-410-21 SWITCH, TACTILE (GROOVE)
S929 1-771-410-21 SWITCH, TACTILE (USB)
S930 1-771-410-21 SWITCH, TACTILE (PRESET EQ)
S931 1-771-410-21 SWITCH, TACTILE (PC(CD))
S932 1-771-410-21 SWITCH, TACTILE (ALBUM + (CD))
S934 1-771-410-21 SWITCH, TACTILE (PAUSE)
S935 1-487-171-11 ROTARY ENCODER (MASTER_VOL)
S936 1-480-581-11 ROTARY ENCODER (OP_DUAL)
S938 1-771-410-21 SWITCH, TACTILE (ENTER)
S940 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S941 1-771-410-21 SWITCH, TACTILE (TAPE)
S942 1-771-410-21 SWITCH, TACTILE (VIDEO)
S945 1-771-410-21 SWITCH, TACTILE (REC TO USB)
************************************************************
SUBTRANS BOARD
***************
< CAPACITOR >
C1200 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-126-942-61 ELECT 1000uF 20% 25V
C1204 1-126-963-11 ELECT 4.7uF 20% 50V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN1201 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(E2, E51, E3)
CN1202 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
(AR, AUS, MX)
CN1200 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN1203 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D1200 6-501-817-01 DIODE MA2J1110GLS0
D1201 6-500-848-01 DIODE MC2840-T112-1
D1202 6-500-848-01 DIODE MC2840-T112-1
D1203 6-500-335-01 DIODE MC2838-T112-1
< TRANSFORMER >
PT1200 1-443-927-11 TRANSFORMER, POWER (SUB) (MX)
PT1200 1-443-927-21 TRANSFORMER, POWER (SUB) (MX)
PT1200 1-443-928-11 TRANSFORMER, POWER (SUB) (EXCEPT MX)
PT1200 1-443-928-21 TRANSFORMER, POWER (SUB) (EXCEPT MX)
< TRANSISTOR >
Q1200 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1201 1-216-819-11 METAL CHIP 680 5% 1/10W
R1202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1205 1-216-845-11 METAL CHIP 100K 5% 1/10W
< RELAY >
RY1200 1-755-334-11 RELAY, AC POWER
< SWITCH >
S1200 1-786-055-31 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E2, E51, E3)
************************************************************
SUBWOOFER BOARD
(GTR7/GTR8/GTR8B)
*****************
< CAPACITOR >
C800 1-126-947-11 ELECT 47uF 20% 35V
C801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-126-963-11 ELECT 4.7uF 20% 50V
C803 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(GTR7/GTR8/GTR8B)
C818 1-126-947-11 ELECT 47uF 20% 35V
(GTR7/GTR8: E2, E51, AR/GTR8B)
STR
SUBTRANS SUBWOOFER
