Sony HCD-GX45 - Electrical Parts List: Power Amp Components (Continued); Transistors on Power Amp; Resistors on Power Amp

71
HCD-GX45/RG440
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
Q5 6-550-289-01 TRANSISTOR 2SA1235F
Q6 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q10 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q11 8-729-055-91 TRANSISTOR SRA2202SF
Q12 6-550-645-01 TRANSISTOR 2SC3143K4-TB
Q13 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q17 6-550-289-01 TRANSISTOR 2SA1235F
Q18 6-550-293-01 FET 2SK2937
Q19 6-550-293-01 FET 2SK2937
Q20 6-550-317-01 TRANSISTOR 2SD814A(RS)
Q21 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q22 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q23 6-550-289-01 TRANSISTOR 2SA1235F
Q24 6-550-289-01 TRANSISTOR 2SA1235F
Q501 6-550-291-01 TRANSISTOR FN1016
Q502 6-550-291-01 TRANSISTOR FN1016
Q503 6-550-292-01 TRANSISTOR FP1016
Q504 6-550-292-01 TRANSISTOR FP1016
Q505 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q506 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q509 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q510 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q511 6-550-413-01 TRANSISTOR 2SC3478LK
Q512 6-550-413-01 TRANSISTOR 2SC3478LK
Q513 6-550-413-01 TRANSISTOR 2SC3478LK
Q514 6-550-413-01 TRANSISTOR 2SC3478LK
Q515 6-550-317-01 TRANSISTOR 2SD814A(RS)
Q516 6-550-317-01 TRANSISTOR 2SD814A(RS)
Q517 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q518 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q519 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q520 6-550-316-01 TRANSISTOR 2SB792A(RS)
Q521 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q522 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q523 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q524 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q525 8-729-052-79 TRANSISTOR 2SD1306NETL
Q526 8-729-052-79 TRANSISTOR 2SD1306NETL
Q527 6-550-289-01 TRANSISTOR 2SA1235F
Q528 8-729-052-79 TRANSISTOR 2SD1306NETL (GX45)
Q529 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q530 6-550-289-01 TRANSISTOR 2SA1235F
Q534 6-550-296-01 TRANSISTOR 2SA1980G
Q535 6-550-296-01 TRANSISTOR 2SA1980G
Q536 6-550-289-01 TRANSISTOR 2SA1235F
< RESISTOR >
R4 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6 1-216-838-11 METAL CHIP 27K 5% 1/10W
R7 1-216-838-11 METAL CHIP 27K 5% 1/10W
R8 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9 1-216-838-11 METAL CHIP 27K 5% 1/10W
R12 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R13 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R14 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R16 1-216-821-11 METAL CHIP 1K 5% 1/10W
R17 1-216-821-11 METAL CHIP 1K 5% 1/10W
R18 1-216-809-11 METAL CHIP 100 5% 1/10W
R19 1-216-835-11 METAL CHIP 15K 5% 1/10W
R20 1-216-833-11 METAL CHIP 10K 5% 1/10W
R21 1-216-835-11 METAL CHIP 15K 5% 1/10W
R22 1-216-839-11 METAL CHIP 33K 5% 1/10W
R23 1-216-839-11 METAL CHIP 33K 5% 1/10W
R26 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R27 1-216-833-11 METAL CHIP 10K 5% 1/10W
R29 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R31 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R32 1-216-840-11 METAL CHIP 39K 5% 1/10W
R33 1-216-839-11 METAL CHIP 33K 5% 1/10W
R34 1-216-843-11 METAL CHIP 68K 5% 1/10W
R35 1-216-840-11 METAL CHIP 39K 5% 1/10W
R36 1-216-839-11 METAL CHIP 33K 5% 1/10W
R37 1-216-843-11 METAL CHIP 68K 5% 1/10W
R38 1-216-833-11 METAL CHIP 10K 5% 1/10W
R39 1-216-845-11 METAL CHIP 100K 5% 1/10W
R40 1-216-833-11 METAL CHIP 10K 5% 1/10W
R41 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R42 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R43 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R44 1-216-236-11 RES-CHIP 39K 5% 1/8W
R45 1-216-841-11 METAL CHIP 47K 5% 1/10W
R46 1-216-841-11 METAL CHIP 47K 5% 1/10W
R47 1-216-837-11 METAL CHIP 22K 5% 1/10W
R48 1-216-849-11 METAL CHIP 220K 5% 1/10W
R49 1-216-849-11 METAL CHIP 220K 5% 1/10W
R50 1-216-833-11 METAL CHIP 10K 5% 1/10W
R51 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R52 1-216-841-11 METAL CHIP 47K 5% 1/10W
R53 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R54 1-216-835-11 METAL CHIP 15K 5% 1/10W
R55 1-260-101-11 CARBON 1.5K 5% 1/2W F
R56 1-249-420-11 CARBON 1.8K 5% 1/4W
R58 1-216-186-00 RES-CHIP 330 5% 1/8W
R59 1-216-184-00 RES-CHIP 270 5% 1/8W
R60 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R61 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R62 1-216-833-11 METAL CHIP 10K 5% 1/10W
R63 1-216-833-11 METAL CHIP 10K 5% 1/10W
R64 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R65 1-216-833-11 METAL CHIP 10K 5% 1/10W
R66 1-216-833-11 METAL CHIP 10K 5% 1/10W
R67 1-216-841-11 METAL CHIP 47K 5% 1/10W
R68 1-216-833-11 METAL CHIP 10K 5% 1/10W
R69 1-216-833-11 METAL CHIP 10K 5% 1/10W
R70 1-216-835-11 METAL CHIP 15K 5% 1/10W
R71 1-216-835-11 METAL CHIP 15K 5% 1/10W
R72 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R73 1-216-236-11 RES-CHIP 39K 5% 1/8W
R74 1-216-238-11 RES-CHIP 47K 5% 1/8W
R75 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
POWER AMP
