HCD-RV2/RV5/RV6
5-5. BASE UNIT SECTION
(BU-30BD62)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
201 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
202 A-4728-371-A BD BOARD, COMPLETE
0203 A-4735-189-A OP ASSY (A-MAX.3)
Ver 1.3
