62
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W
*************************************************************
1-685-092-11 KEY BOARD (RV2)
1-685-100-11 KEY BOARD (RV5)
1-685-108-11 KEY BOARD (RV6)
**********
< DIODE >
LED707 8-719-058-03 LED SEL5423E-TP15 (GAME MIXING)
LED708 8-719-058-04 LED SEL5223S-TP15 (ENTER) (RV5/RV6)
< RESISTOR >
R716 1-249-425-11 CARBON 4.7K 5% 1/4W
R717 1-249-427-11 CARBON 6.8K 5% 1/4W
R718 1-249-429-11 CARBON 10K 5% 1/4W
(RV5/RV6)
R719 1-249-431-11 CARBON 15K 5% 1/4W
(RV5/RV6)
R720 1-249-433-11 CARBON 22K 5% 1/4W
(RV5/RV6)
R721 1-249-435-11 CARBON 33K 5% 1/4W
(RV5/RV6)
R722 1-249-413-11 CARBON 470 5% 1/4W
R723 1-249-415-11 CARBON 680 5% 1/4W
R724 1-249-417-11 CARBON 1K 5% 1/4W
R725 1-249-419-11 CARBON 1.5K 5% 1/4W
R726 1-249-419-11 CARBON 1.5K 5% 1/4W
R727 1-249-421-11 CARBON 2.2K 5% 1/4W
R728 1-247-843-11 CARBON 3.3K 5% 1/4W
R729 1-249-425-11 CARBON 4.7K 5% 1/4W
R730 1-249-427-11 CARBON 6.8K 5% 1/4W
R731 1-249-429-11 CARBON 10K 5% 1/4W
R732 1-249-431-11 CARBON 15K 5% 1/4W
(RV5/RV6)
R733 1-249-433-11 CARBON 22K 5% 1/4W
(RV5/RV6)
R734 1-249-435-11 CARBON 33K 5% 1/4W
(RV5/RV6)
R735 1-249-427-11 CARBON 6.8K 5% 1/4W
R736 1-249-429-11 CARBON 10K 5% 1/4W
R737 1-249-431-11 CARBON 15K 5% 1/4W
R738 1-249-433-11 CARBON 22K 5% 1/4W
R754 1-249-435-11 CARBON 33K 5% 1/4W
< SWITCH >
S717 1-762-875-21 SWITCH, KEYBOARD (GAME EQ)
S718 1-762-875-21 SWITCH, KEYBOARD (MUSIC EQ)
S719 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
(RV5/RV6)
S720 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING) (RV5/RV6)
S721 1-762-875-21 SWITCH, KEYBOARD (GROOVE) (RV5/RV6)
S722 1-762-875-21 SWITCH, KEYBOARD (PICTURE EFFECT)
(RV5/RV6)
S723 1-762-875-21 SWITCH, KEYBOARD (X)
S724 1-762-875-21 SWITCH, KEYBOARD (x)
S725 1-762-875-21 SWITCH, KEYBOARD (ALBUM +)
S726 1-762-875-21 SWITCH, KEYBOARD (>)
S727 1-762-875-21 SWITCH, KEYBOARD (M +)
S728 1-762-875-21 SWITCH, KEYBOARD (G) (RV2)
S728 1-762-875-21 SWITCH, KEYBOARD (gG) (RV5/RV6)
S729 1-762-875-21 SWITCH, KEYBOARD (– m)
S730 1-762-875-21 SWITCH, KEYBOARD (ALBUM –)
S731 1-762-875-21 SWITCH, KEYBOARD (.)
S732 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING) (RV2)
S732 1-762-875-21 SWITCH, KEYBOARD (b) (RV5/RV6)
S733 1-762-875-21 SWITCH, KEYBOARD (V) (RV5/RV6)
S734 1-762-875-21 SWITCH, KEYBOARD (B) (RV5/RV6)
S735 1-762-875-21 SWITCH, KEYBOARD (v) (RV5/RV6)
S736 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S737 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S738 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF) (RV2)
S738 1-762-875-21 SWITCH, KEYBOARD (P FILE) (RV5/RV6)
S739 1-762-875-21 SWITCH, KEYBOARD (GROOVE) (RV2)
S739 1-762-875-21 SWITCH, KEYBOARD (ENTER) (RV5/RV6)
S740 1-762-875-21 SWITCH, KEYBOARD (MOVE EQ)
S741 1-762-875-21 SWITCH, KEYBOARD (SPEAKER MODE) (RV6)
S742 1-762-875-21 SWITCH, KEYBOARD (DISPLAY) (RV2)
*************************************************************
A-4676-995-A MAIN BOARD, COMPLETE (RV2:E3,MY,SP)
A-4729-270-A MAIN BOARD, COMPLETE (RV5:E3,JE,MY,SP)
A-4729-402-A MAIN BOARD, COMPLETE (RV6:E3,MY,SP)
A-4730-979-A MAIN BOARD, COMPLETE (RV2:EA)
A-4730-982-A MAIN BOARD, COMPLETE (RV2:TH)
A-4730-986-A MAIN BOARD, COMPLETE (RV5:EA)
A-4730-988-A MAIN BOARD, COMPLETE (RV5:TH)
A-4730-990-A MAIN BOARD, COMPLETE (RV6:EA)
A-4730-992-A MAIN BOARD, COMPLETE (RV6:TH)
*********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C100 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-126-947-11 ELECT 47uF 20% 16V
C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-126-947-11 ELECT 47uF 20% 16V
C107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-126-962-11 ELECT 3.3uF 20% 50V
C109 1-162-940-11 CERAMIC CHIP 9PF 0.5PF 50V
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C112 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C113 1-126-959-11 ELECT 0.47uF 20% 50V
C114 1-126-947-11 ELECT 47uF 20% 16V
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-126-961-11 ELECT 2.2uF 20% 50V
C117 1-126-947-11 ELECT 47uF 20% 16V
C118 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
