66
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< EARTH TERMINAL >
* GND1 1-537-738-21 TERMINAL, EARTH
< IC >
IC101 8-759-828-33 IC LA1845
IC102 6-702-258-01 IC LC72121
IC201 6-702-130-01 IC HA12237F
IC301 6-702-422-11 IC M61519FPD61G
IC302 8-759-710-97 IC NJM4565M-D
IC304 8-759-652-01 IC LA2615 (RV5/RV6)
IC601 6-801-340-01 IC M30620MCN-A02FP
IC602 6-700-915-01 IC SN74AHCT04PWR
IC661 8-759-533-04 IC M62703ML-E1
IC681 8-759-039-69 IC uPC7805AHF
IC682 6-701-760-01 IC uPC3504AHF
IC683 8-759-088-08 IC uPC7812AHF
IC684 8-759-701-59 IC NJM78M09FA
IC685 8-759-039-69 IC uPC7805AHF
< IFT >
IFT101 1-435-848-12 TRANSFORMER, IF (CERAMIC FILTER)
< TERMINAL BOARD >
JK101 1-694-555-12 TERMINAL BOARD (4P) (ANTENNA)
JK302 1-694-635-12 TERMINAL BOARD (4P) (SPEAKER L/R)
< JACK >
JK301 1-770-613-11 JACK, PIN 4P (MD (VIDEO) IN/OUT)
(RV5/RV6)
< JUMPER RESISTOR >
JR104 1-216-864-11 METAL CHIP 0 5% 1/10W
JR105 1-216-864-11 METAL CHIP 0 5% 1/10W
JR106 1-216-864-11 METAL CHIP 0 5% 1/10W
JR107 1-216-864-11 METAL CHIP 0 5% 1/10W
JR108 1-216-864-11 METAL CHIP 0 5% 1/10W
JR110 1-216-864-11 METAL CHIP 0 5% 1/10W
JR111 1-216-864-11 METAL CHIP 0 5% 1/10W
JR112 1-216-864-11 METAL CHIP 0 5% 1/10W
JR113 1-216-864-11 METAL CHIP 0 5% 1/10W
JR114 1-216-864-11 METAL CHIP 0 5% 1/10W
JR116 1-216-864-11 METAL CHIP 0 5% 1/10W
JR201 1-216-864-11 METAL CHIP 0 5% 1/10W
JR202 1-216-864-11 METAL CHIP 0 5% 1/10W
JR321 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV5/RV6)
JR322 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV5/RV6)
JR323 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV5/RV6)
JR361 1-216-864-11 METAL CHIP 0 5% 1/10W
JR601 1-216-864-11 METAL CHIP 0 5% 1/10W
JR602 1-216-864-11 METAL CHIP 0 5% 1/10W
JR638 1-216-864-11 METAL CHIP 0 5% 1/10W
JR670 1-216-295-11 SHORT CHIP 0 (RV2)
JR671 1-216-864-11 METAL CHIP 0 5% 1/10W
JR672 1-216-864-11 METAL CHIP 0 5% 1/10W
JR673 1-216-864-11 METAL CHIP 0 5% 1/10W
JR674 1-216-864-11 METAL CHIP 0 5% 1/10W
JR675 1-216-864-11 METAL CHIP 0 5% 1/10W
JR676 1-216-864-11 METAL CHIP 0 5% 1/10W
JR677 1-216-864-11 METAL CHIP 0 5% 1/10W
JR678 1-216-864-11 METAL CHIP 0 5% 1/10W
JR679 1-216-864-11 METAL CHIP 0 5% 1/10W
JR680 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
L250 1-456-168-11 COIL (OSC) (RV5/RV6)
L250 1-456-169-11 COIL (OSC) (RV2)
< TRANSISTOR >
Q101 8-729-922-66 TRANSISTOR 2SC2410SN
Q102 8-729-422-57 TRANSISTOR UN4111
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q104 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q250 8-729-142-46 TRANSISTOR 2SC2001-LK
Q251 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q252 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q253 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q254 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q255 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q256 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q257 8-729-140-04 TRANSISTOR 2SB1116A-L
Q258 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q261 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q262 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q264 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q301 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q302 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q304 8-729-900-63 TRANSISTOR DTA124ES (RV5/RV6)
Q307 8-729-119-78 TRANSISTOR 2SC2785-HFE (RV2)
Q308 8-729-119-78 TRANSISTOR 2SC2785-HFE (RV2)
Q361 8-729-116-02 TRANSISTOR BA1A4M-TP
Q362 8-729-900-63 TRANSISTOR DTA124ES
Q363 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q364 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q365 8-729-900-63 TRANSISTOR DTA124ES
Q366 8-729-119-78 TRANSISTOR 2SC2785-HFE (RV5/RV6)
Q367 8-729-119-78 TRANSISTOR 2SC2785-HFE (RV5/RV6)
Q368 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q369 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q371 8-729-142-46 TRANSISTOR 2SC2001-LK (RV5/RV6)
Q381 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q382 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q383 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q384 8-729-116-02 TRANSISTOR BA1A4M-TP
Q385 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q386 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q387 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q388 8-729-116-02 TRANSISTOR BA1A4M-TP (RV6)
Q421 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q422 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q451 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q452 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q453 8-729-027-31 TRANSISTOR DTA124EKA-T146
