74
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R787 1-249-437-11 CARBON 47K 5% 1/4W
R788 1-247-807-31 CARBON 100 5% 1/4W
R789 1-249-429-11 CARBON 10K 5% 1/4W
R790 1-247-885-00 CARBON 180K 5% 1/4W
R791 1-247-807-31 CARBON 100 5% 1/4W
R792 1-249-441-11 CARBON 100K 5% 1/4W
R795 1-249-431-11 CARBON 15K 5% 1/4W
R796 1-249-401-11 CARBON 47 5% 1/4W
R799 1-249-401-11 CARBON 47 5% 1/4W
R800 1-249-429-11 CARBON 10K 5% 1/4W
R801 1-247-804-11 CARBON 75 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-249-437-11 CARBON 47K 5% 1/4W
< VIBRATOR >
RES701 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
< SWITCH >
S701 1-762-875-21 SWITCH, KEYBOARD (CD)
S702 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S703 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S704 1-762-875-21 SWITCH, KEYBOARD (MD (VIDEO))
S705 1-762-875-21 SWITCH, KEYBOARD (GAME)
S706 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON)
S707 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S708 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S709 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S710 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S711 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE Z)
S712 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S713 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY/
PLAY MODE)
S714 1-762-875-21 SWITCH, KEYBOARD (FM MODE/REPEAT)
S715 1-762-875-21 SWITCH, KEYBOARD (DIRECTION/EDIT)
S716 1-762-875-21 SWITCH, KEYBOARD (?/1)
S742 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< ROTARY ENCODER >
VR701 1-418-725-41 ENCODER, ROTARY (VOLUME)
< VARIABLE RESISTOR >
VR702 1-225-739-11 RES, VAR, CARBON 50K (ECHO LEVEL)
VR703 1-225-739-11 RES, VAR, CARBON 50K (MIC LEVEL)
*************************************************************
A-4729-403-A PANEL BOARD, COMPLETE (RV6)
**********************
4-238-647-01 HOLDER (L), FL
4-238-648-01 HOLDER (R), FL
< CAPACITOR >
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-126-964-11 ELECT 10uF 20% 50V
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-126-947-11 ELECT 47uF 20% 10V
C705 1-162-294-31 CERAMIC 0.001uF 10% 50V
C706 1-162-294-31 CERAMIC 0.001uF 10% 50V
C707 1-162-294-31 CERAMIC 0.001uF 10% 50V
C708 1-162-282-31 CERAMIC 100PF 10% 50V
C710 1-162-282-31 CERAMIC 100PF 10% 50V
C711 1-162-282-31 CERAMIC 100PF 10% 50V
C713 1-162-282-31 CERAMIC 100PF 10% 50V
C716 1-161-494-00 CERAMIC 0.022uF 25V
C718 1-162-306-11 CERAMIC 0.01uF 30% 16V
C719 1-162-219-31 CERAMIC 68PF 5% 50V
C720 1-162-306-11 CERAMIC 0.01uF 30% 16V
C721 1-126-947-11 ELECT 47uF 20% 10V
C722 1-162-282-31 CERAMIC 100PF 10% 50V
C723 1-162-282-31 CERAMIC 100PF 10% 50V
C724 1-162-282-31 CERAMIC 100PF 10% 50V
C725 1-162-282-31 CERAMIC 100PF 10% 50V
C726 1-162-282-31 CERAMIC 100PF 10% 50V
C727 1-162-282-31 CERAMIC 100PF 10% 50V
C728 1-162-282-31 CERAMIC 100PF 10% 50V
C729 1-162-282-31 CERAMIC 100PF 10% 50V
C730 1-162-282-31 CERAMIC 100PF 10% 50V
C731 1-162-282-31 CERAMIC 100PF 10% 50V
C732 1-162-282-31 CERAMIC 100PF 10% 50V
C733 1-162-282-31 CERAMIC 100PF 10% 50V
C734 1-162-306-11 CERAMIC 0.01uF 30% 16V
C735 1-162-306-11 CERAMIC 0.01uF 30% 16V
C736 1-162-294-31 CERAMIC 0.001uF 10% 50V
C737 1-162-294-31 CERAMIC 0.001uF 10% 50V
C738 1-104-665-11 ELECT 100uF 20% 10V
C739 1-104-665-11 ELECT 100uF 20% 10V
C740 1-126-959-11 ELECT 0.47uF 20% 50V
C741 1-126-959-11 ELECT 0.47uF 20% 50V
C742 1-130-493-00 MYLAR 0.068uF 5% 50V
C744 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C745 1-126-960-11 ELECT 1uF 20% 50V
C747 1-136-167-00 FILM 0.15uF 5% 50V
C748 1-126-947-11 ELECT 47uF 20% 16V
C749 1-130-493-00 MYLAR 0.068uF 5% 50V
C750 1-162-294-31 CERAMIC 0.001uF 10% 50V
C751 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C752 1-126-960-11 ELECT 1uF 20% 50V
C753 1-110-671-31 CERAMIC 0.047uF 50V
C754 1-162-215-31 CERAMIC 47PF 5% 50V
C755 1-126-957-11 ELECT 0.22uF 20% 50V
C756 1-162-294-31 CERAMIC 0.001uF 10% 50V
C757 1-162-306-11 CERAMIC 0.01uF 30% 16V
C758 1-126-956-11 ELECT 0.1uF 20% 50V
C759 1-162-290-31 CERAMIC 470PF 10% 50V
C760 1-126-961-11 ELECT 2.2uF 20% 50V
C761 1-162-215-31 CERAMIC 47PF 5% 50V
C762 1-162-282-31 CERAMIC 100PF 10% 50V
C763 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-126-961-11 ELECT 2.2uF 20% 50V
C765 1-126-964-11 ELECT 10uF 20% 50V
C766 1-126-964-11 ELECT 10uF 20% 50V
C767 1-164-159-21 CERAMIC 0.1uF 50V
C770 1-164-159-21 CERAMIC 0.1uF 50V
C771 1-126-964-11 ELECT 10uF 20% 50V
C772 1-126-964-11 ELECT 10uF 20% 50V
PANEL
