81
HCD-RV2/RV5/RV6
C223 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C224 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C255 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C257 1-128-065-11 ELECT CHIP 68uF 20% 10V
C258 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C259 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C301 1-124-779-00 ELECT CHIP 10uF 20% 16V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-124-779-00 ELECT CHIP 10uF 20% 16V
C305 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C307 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C308 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C309 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C311 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C312 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C313 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C314 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C315 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C317 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C318 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C322 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C323 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C324 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C325 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C326 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C327 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C328 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C329 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C338 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C339 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C360 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C361 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C363 1-124-779-00 ELECT CHIP 10uF 20% 16V
C364 1-124-779-00 ELECT CHIP 10uF 20% 16V
C365 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C366 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C501 1-124-779-00 ELECT CHIP 10uF 20% 16V
C502 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C522 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C523 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C524 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C525 1-126-193-11 ELECT 1uF 20% 50V
C533 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C534 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C535 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C536 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C537 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C538 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C540 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C541 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C542 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C543 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C544 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C545 1-126-193-11 ELECT 1uF 20% 50V
C546 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C547 1-126-193-11 ELECT 1uF 20% 50V
C548 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C549 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C550 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C551 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C552 1-126-193-11 ELECT 1uF 20% 50V
C561 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C566 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C567 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C570 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C571 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C572 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C573 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C574 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C575 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C576 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C581 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C582 1-124-779-00 ELECT CHIP 10uF 20% 16V
C583 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C584 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C596 1-124-779-00 ELECT CHIP 10uF 20% 16V
C597 1-124-779-00 ELECT CHIP 10uF 20% 16V
< CONNECTOR >
CN101 1-784-327-21 CONNECTOR, FFC/FPC 28P
CN201 1-778-874-11 CONNECTOR, FFC (LIF(NON-ZIF)) 19P
CN301 1-794-509-11 PIN, CONNECTOR (PC BOARD) 3P
< FERRITE BEAD >
FB201 1-469-869-21 INDUCTOR (EMI FERRITE)
FB251 1-469-869-21 INDUCTOR (EMI FERRITE)
FB252 1-469-869-21 INDUCTOR (EMI FERRITE)
FB360 1-469-869-21 INDUCTOR (EMI FERRITE)
FB501 1-469-869-21 INDUCTOR (EMI FERRITE)
FB502 1-469-869-21 INDUCTOR (EMI FERRITE)
FB503 1-469-869-21 INDUCTOR (EMI FERRITE)
FB504 1-469-869-21 INDUCTOR (EMI FERRITE)
FB561 1-469-869-21 INDUCTOR (EMI FERRITE)
< FILTER >
FL201 1-234-177-21 FILTER, CHIP EMI
FL501 1-234-177-21 FILTER, CHIP EMI
FL502 1-234-177-21 FILTER, CHIP EMI
FL503 1-234-177-21 FILTER, CHIP EMI
FL504 1-234-177-21 FILTER, CHIP EMI
< IC >
IC102 8-759-701-40 IC NJM3404AM-T1
IC201 6-700-399-01 IC uPC2925T-E1
IC202 8-759-460-72 IC BA033FP-E2
IC301 8-759-514-57 IC BA7046F
IC302 8-759-530-30 IC TC74VHCU04FT(EL)
VIDEO
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
