83
HCD-RV2/RV5/RV6
X502 1-767-519-11 VIBRATOR, CRYSTAL (29MHz)
*************************************************************
1-685-096-11 VIDEO OUT BOARD (RV2)
1-685-104-11 VIDEO OUT BOARD (RV5)
1-685-112-11 VIDEO OUT BOARD (RV6)
****************
< CONNECTOR >
* CN605 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< JACK >
JK602 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
*************************************************************
MISCELLANEOUS
***************
61-824-753-11 WIRE (FLAT TYPE) (28 CORE)
14 1-590-578-11 WIRE (FLAT TYPE) (19 CORE)
70 1-796-485-11 MECHANISM DECK, TAPE (RV2)
70 1-796-487-11 MECHANISM DECK, TAPE (RV5/RV6)
101 1-751-688-11 WIRE (FLAT TYPE) (13 CORE)
0107 1-777-071-82 CORD, POWER (RV2:EA,MY,SP/RV5:JE,MY,SP/
RV6:EA,MY,SP)
0107 1-791-901-12 CORD, POWER (E3,TH)
0107 1-823-767-11 CORD, POWER (RV5:EA)
108 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
165 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
201 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0203 A-4735-189-A OP ASSY (A-MAX.3)
0F914 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(RV2/RV6)
0F914 1-533-949-31 FUSE, CYLINDRICAL (TIME LAG)
(T8AL/250V) (RV5)
0F919 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (T4AL/250V)
(RV2:E3,EA,MY,SP/RV6:E3,EA,MY,SP)
0F919 1-533-472-11 FUSE, GLASS TUBE (DIA.5) (T5AL/250V)
(RV5:E3,EA,JE,MY,SP)
0F920 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(RV2/RV6)
0F920 1-533-949-31 FUSE, CYLINDRICAL (TIME LAG)
(T8AL/250V) (RV5)
FAN961 1-763-072-11 FAN, DC (RV5/RV6)
0T911 1-437-222-11 TRANSFORMER, POWER (RV5:E3,JE,MY,SP,TH)
0T911 1-437-764-11 TRANSFORMER, POWER (RV2:E3,MY,SP,TH)
0T911 1-437-765-11 TRANSFORMER, POWER (RV6:E3,MY,SP,TH)
0T911 1-437-831-11 TRANSFORMER, POWER (RV2:EA)
0T911 1-437-832-11 TRANSFORMER, POWER (RV5:EA)
0T911 1-437-833-11 TRANSFORMER, POWER (RV6:EA)
M721 A-4672-826-A MOTOR ASSY (OPEN/CLOSE)
VIDEO OUTVIDEO
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Ver 1.4
