11
HCD-RV7/RV8
qd
9
7
two
screws (PTPWH M2.6
qs
screw (PTPWH M2.6)
8
screws (DIA. 12)
5
two screws (BVTP 2.6
×
8)
4
BD board
3
Remove the four solders of
sled motor and spindle motors.
0
two insulators (BU-30)
qf
holder (BU) (BU-30) assy
0
two insulators (BU-30)
6
two stoppers (BU)
2
wire (flat type) (16 core)
(CN102)
qa
BU-30 (61) assy
1
wire (flat type) (28 core)
(CN101)
3-8. BU-30 (61) ASSY
3-9. DRIVER BOARD, MOTOR BOARD, SENSOR (CD) BOARD AND VIDEO BOARD
4
Pull out the disc table.
9
two
screws (BVTP 2.6
×
8)
qf
screw (PTPWH 2.6
×
8)
qg
tray
6
s
crew (BVTP 2.6
×
8)
qh
screw (BVTP 2.6
×
8)
0
qd
motor board
qj
sensor (CD)
board
7
driver board
3
video board
2
two s
crews
(BVTP 2.6
×
8)
8
Remove the two solderings of motor.
qs
connector
(CN722)
5
wire (flat type) (8 core)
(CN702)
qa
wire (flat type) (8 core)
(CN721)
1
wire (flat type) (28 core)
(CN101)
