Sony HCD-RX30 - FILTERS, FRONT-END COMPONENTS, IFTs, JUMPER RESISTORS

— 79 —
Ref. No. Part No. Description Remark
C24 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C26 1-126-967-11 ELECT 47uF 20% 16V
C28 1-126-967-11 ELECT 47uF 20% 16V
C29 1-162-306-11 CERAMIC 0.01uF 30% 16V
C30 1-126-961-11 ELECT 2.2uF 20% 100V
C31 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C32 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C33 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C34 1-163-091-00 CERAMIC CHIP 8PF 50V (G)
C34 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(AEP,UK,EE)
C35 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C36 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C37 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C39 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C40 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C41 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C42 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C43 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C44 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C45 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C46 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C47 1-126-967-11 ELECT 47uF 20% 16V
C48 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C49 1-126-959-11 ELECT 0.47uF 20% 50V
C50 1-126-960-11 ELECT 1.0uF 20% 50V
C51 1-126-960-11 ELECT 1.0uF 20% 50V
C52 1-126-963-11 ELECT 4.7uF 20% 50V
(AEP, UK, G)
C52 1-126-964-11 ELECT 10uF 20% 50V (EE)
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-104-396-11 ELECT 10uF 20% 16V
C55 1-104-396-11 ELECT 10uF 20% 16V
C56 1-104-396-11 ELECT 10uF 20% 16V
C57 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C58 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C59 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(AEP,UK,G)
C59 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V (EE)
C60 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(AEP,UK,G)
C60 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V (EE)
C61 1-126-301-11 ELECT 1uF 20% 50V
C62 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C63 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C64 1-126-967-11 ELECT 47uF 20% 16V
C65 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C66 1-126-162-11 ELECT 3.3uF 20% 50V
C67 1-126-933-11 ELECT 100uF 20% 10V
C68 1-162-306-11 CERAMIC 0.01uF 30% 16V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
C72 1-126-967-11 ELECT 47uF 20% 16V
C120 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
(AEP,UK,G)
< FILTER >
CF1 1-567-389-11 FILTER, CERAMIC
CF2 1-760-393-11 FILTER, CERAMIC (AEP,UK,G)
CF3 1-567-389-11 FILTER, CERAMIC (EE)
Ref. No. Part No. Description Remark
CF3 1-760-393-11 FILTER, CERAMIC (AEP,UK,G)
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< DIODE >
D21 8-719-976-99 DIODE UDZ-TE-17-5.1B
D41 8-719-016-74 DIODE 1SS352-TPH3
< FRONT-END >
FE1 1-233-542-11 FRONT END (4 GANG)(AEP,UK,G)
FE1 1-693-335-11 FRONT END (3 GANG)(EE)
FE2 1-233-514-11 ENCAPSULATED COMPONENT (AEP,UK,EE)
FE2 1-239-260-11 ENCAPSULATED COMPONENT (G)
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< JUMPER RESISTOR >
JR1 1-216-295-11 METAL CHIP 0 5% 1/10W
(G)
JR2 1-216-295-11 METAL CHIP 0 5% 1/10W
(AEP,UK,EE)
JR3 1-216-295-11 METAL CHIP 0 5% 1/10W
(G)
JR6 1-216-295-11 METAL CHIP 0 5% 1/10W
(AEP,UK,G)
JR7 1-216-295-11 METAL CHIP 0 5% 1/10W
(G)
JR8 1-216-295-11 METAL CHIP 0 5% 1/10W
(AEP,UK,EE)
JR9 1-216-295-11 METAL CHIP 0 5% 1/10W
(AEP,UK,EE)
JR45 1-216-295-11 METAL CHIP 0 5% 1/10W
JR46 1-216-296-11 METAL CHIP 0 5% 1/8W
JR47 1-216-295-11 METAL CHIP 0 5% 1/10W
JR48 1-216-295-11 METAL CHIP 0 5% 1/10W
JR49 1-216-296-11 METAL CHIP 0 5% 1/8W
JR51 1-216-295-11 METAL CHIP 0 5% 1/10W
(AEP,UK,EE)
JR52 1-216-295-11 METAL CHIP 0 5% 1/10W
JR53 1-216-296-11 METAL CHIP 0 5% 1/8W
(AEP,UK,EE)
JR54 1-216-295-11 METAL CHIP 0 5% 1/10W
< JUMPER RESISTOR >
JW4 1-249-413-11 CARBON 470 5% 1/4W
(AEP,UK,G)
JW5 1-249-413-11 CARBON 470 5% 1/4W
(AEP,UK,G)
< COIL >
L2 1-414-142-11 MICRO INDUCTOR 1uH (AEP,UK,G)
L3 1-410-521-11 MICRO INDUCTOR 100uH
TCB
