Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
67
HCD-SPZ50/SPZ70
R949 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R950 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-216-833-11 METAL CHIP 10K 5% 1/10W
R952 1-216-813-11 METAL CHIP 220 5% 1/10W
R953 1-216-813-11 METAL CHIP 220 5% 1/10W
R954 1-216-813-11 METAL CHIP 220 5% 1/10W
R955 1-216-813-11 METAL CHIP 220 5% 1/10W
R956 1-216-817-11 METAL CHIP 470 5% 1/10W
R957 1-216-817-11 METAL CHIP 470 5% 1/10W
R958 1-216-813-11 METAL CHIP 220 5% 1/10W
R959 1-216-813-11 METAL CHIP 220 5% 1/10W
R960 1-216-809-11 METAL CHIP 100 5% 1/10W
R961 1-216-821-11 METAL CHIP 1K 5% 1/10W
R962 1-216-821-11 METAL CHIP 1K 5% 1/10W
R963 1-216-821-11 METAL CHIP 1K 5% 1/10W
R964 1-216-821-11 METAL CHIP 1K 5% 1/10W
R965 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(SPZ50)
R965 1-216-864-11 SHORT CHIP 0 (SPZ70)
R966 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(SPZ50)
R967 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SPZ50)
R968 1-216-813-11 METAL CHIP 220 5% 1/10W
R969 1-216-813-11 METAL CHIP 220 5% 1/10W
R970 1-216-813-11 METAL CHIP 220 5% 1/10W
R971 1-216-813-11 METAL CHIP 220 5% 1/10W
R972 1-216-817-11 METAL CHIP 470 5% 1/10W
R973 1-216-817-11 METAL CHIP 470 5% 1/10W
R974 1-216-813-11 METAL CHIP 220 5% 1/10W
R975 1-216-813-11 METAL CHIP 220 5% 1/10W
R976 1-216-809-11 METAL CHIP 100 5% 1/10W
R977 1-216-821-11 METAL CHIP 1K 5% 1/10W
R978 1-216-821-11 METAL CHIP 1K 5% 1/10W
R979 1-216-821-11 METAL CHIP 1K 5% 1/10W
R980 1-216-821-11 METAL CHIP 1K 5% 1/10W
R981 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R982 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R983 1-216-833-11 METAL CHIP 10K 5% 1/10W
R984 1-216-813-11 METAL CHIP 220 5% 1/10W
R985 1-216-813-11 METAL CHIP 220 5% 1/10W
R986 1-216-813-11 METAL CHIP 220 5% 1/10W
R987 1-216-813-11 METAL CHIP 220 5% 1/10W
R988 1-216-817-11 METAL CHIP 470 5% 1/10W
R989 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R990 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R991 1-216-821-11 METAL CHIP 1K 5% 1/10W
R992 1-216-833-11 METAL CHIP 10K 5% 1/10W
< ROTARY ENCODER >
RV951 1-478-061-11 ENCODER, ROTARY (PUSH ENTER, JOG)
RV952 1-479-670-11 ENCODER, ROTARY (VOLUME)
RV953 1-418-859-31 ENCODER, ROTARY (TREBLE) (SPZ70)
RV954 1-418-859-31 ENCODER, ROTARY (BASS) (SPZ70)
< SWITCH >
S951 1-762-875-21 SWITCH, KEYBOARD (I/1)
S952 1-762-875-21 SWITCH, KEYBOARD (TAPE u)
S953 1-762-875-21 SWITCH, KEYBOARD (CD u)
S954 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S955 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S956 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S957 1-762-875-21 SWITCH, KEYBOARD (EQ) (SPZ50)
S957 1-762-875-21 SWITCH, KEYBOARD (SOURCE DIRECT)
(SPZ70)
S958 1-762-875-21 SWITCH, KEYBOARD (EQ LEVEL –) (SPZ50)
S959 1-762-875-21 SWITCH, KEYBOARD (EQ LEVEL +) (SPZ50)
S961 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S962 1-762-875-21 SWITCH, KEYBOARD (x, CANCEL)
S963 1-762-875-21 SWITCH, KEYBOARD (M L, TUNING +)
S964 1-762-875-21 SWITCH, KEYBOARD (l m, TUNING –)
S965 1-762-875-21 SWITCH, KEYBOARD (SELECT FOLDER +)
S966 1-762-875-21 SWITCH, KEYBOARD (SELECT FOLDER –)
S968 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S969 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S970 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S971 1-762-875-21 SWITCH, KEYBOARD (Z)
S972 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S973 1-762-875-21 SWITCH, KEYBOARD (REPEAT/FM MODE)
S974 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
************************************************************
A-1166-887-A POWER BOARD, COMPLETE (SPZ70: AR, KR)
A-1166-887-A POWER BOARD, COMPLETE (TYPE B, TYPE C)
(SPZ70: AEP, UK, RU)
A-1167-006-A POWER BOARD, COMPLETE
(SPZ50: SP, KR, AUS)
A-1167-006-A POWER BOARD, COMPLETE (TYPE B, TYPE C)
(SPZ50: AEP, UK, RU)
A-1171-392-A POWER BOARD, COMPLETE (SPZ70: E2, E51)
A-1173-190-A POWER BOARD, COMPLETE (SPZ70: MX)
A-1191-115-A POWER BOARD, COMPLETE (TYPE A)
(SPZ70: AEP, UK, RU)
A-1191-116-A POWER BOARD, COMPLETE (TYPE A)
(SPZ50: AEP, UK, RU)
***********************
1-533-233-31 FUSE HOLDER
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
0 C1 1-165-529-11 MYLAR 0.22uF 10 275V
0 C2 1-165-529-11 MYLAR 0.22uF 10 275V
0 C4 1-119-886-51 CERAMIC 470PF 10% 250V
0 C5 1-119-886-51 CERAMIC 470PF 10% 250V
0 C11 1-100-877-11 ELECT (BLOCK) 270uF 20% 250V
(SPZ70: E2, E51, MX)
0 C11 1-100-923-21 ELECT 100uF 20% 450V
(SPZ70: AEP, UK, RU, AR)
0 C11 1-112-865-21 ELECT 82uF 20% 450V
(SPZ50)
0 C12 1-100-877-11 ELECT (BLOCK) 270uF 20% 250V
(SPZ70: E2, E51, MX)
0 C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0 C14 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
0 C15 1-126-964-11 ELECT 10uF 20% 50V
0 C16 1-126-963-11 ELECT 4.7uF 20% 50V
0 C17 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
PANEL POWER
Ver. 1.3
Note: Refer to the Servicing Notes “NOTE OF REPLACING MAIN
BOARD, IC1301 (MAIN BOARD), C25 (POWER BOARD)
OR POWER BOARD” (page 4), when you exchange the
POWER board.
