Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
68
HCD-SPZ50/SPZ70
0C18 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0C19 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0C20 1-126-947-11 ELECT 47uF 20% 35V
0C21 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
0C22 1-107-824-11 CERAMIC 220PF 5% 1KV
0C23 1-107-824-11 CERAMIC 220PF 5% 1KV
0C24 1-165-609-11 FILM 27000PF 3% 800V
(SPZ50)
0C24 1-165-610-11 FILM 33000PF 3% 800V
(SPZ70)
0C25 1-126-948-11 ELECT 100uF 20% 35V
(TYPE A)
(SPZ50: AEP, UK, RU/SPZ70: AEP, UK, RU)
0C25 1-126-950-11 ELECT 330uF 20% 35V
(TYPE B, TYPE C)
0C26 1-112-877-51 CERAMIC 0.001uF 20% 250V
C31 1-112-238-21 ELECT 470uF 20% 25V
C32 1-112-254-21 ELECT 1000uF 20% 35V
(SPZ50)
C32 1-137-806-21 ELECT 1800uF 20% 35V
(SPZ70)
0C602 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
0C603 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
0C604 1-126-964-11 ELECT 10uF 20% 50V
0C606 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C609 1-126-964-11 ELECT 10uF 20% 50V
C651 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C652 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C653 1-126-923-91 ELECT 220uF 20% 10V
C654 1-104-658-91 ELECT 100uF 20% 10V
< CONNECTOR >
0CN1 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN31 1-819-132-11 PIN, CONNECTOR 4P
CN32 1-819-130-11 PIN, CONNECTOR 2P
CN604 1-815-444-11 PIN, CONNECTOR (PWB) 3P
< DIODE >
0D1 8-719-077-77 DIODE D3SB60F3
0D2 8-719-081-58 DIODE S2V60-TA (SPZ70: E2, E51, MX)
0D3 8-719-081-58 DIODE S2V60-TA (SPZ70: E2, E51, MX)
0D11 8-719-979-64 DIODE UF4005/23
0D14 6-500-567-31 DIODE 10ERB20-TB3
0D15 6-501-178-01 DIODE UDZW-TE17-15B
0D16 6-501-178-01 DIODE UDZW-TE17-15B
0D17 6-500-137-01 DIODE BAT54HT1
D31 8-719-510-09 DIODE D10SC6M
D32 8-719-074-58 DIODE FCH10A10
D33 8-719-924-32 DIODE MTZJ-T-77-24D (SPZ50)
D33 8-719-982-15 DIODE MTZJ-27B (SPZ70)
0D602 8-719-073-23 DIODE ST02D-200TA
0D603 6-500-567-31 DIODE 10ERB20-TB3
D604 6-500-567-31 DIODE 10ERB20-TB3
D652 8-719-071-26 DIODE HZU18B3TRF
< FUSE >
0F1 1-576-232-51 FUSE (5A/250V)
< FERRITE BEAD >
0 FB11 1-410-397-21 FERRITE 1.1uH
< IC >
0 IC11 6-707-749-01 IC CXD9841P
0 IC601 6-708-726-01 IC MIP2F20MS1SO
IC650 6-705-280-01 IC FAN431AZXA
< COIL >
L602 1-412-525-31 INDUCTOR 10uH
< PHOTO COUPLER >
0 PH11 6-600-438-01 PHOTO COUPLER TLP421F (D4-GR)
0 PH601 6-600-438-01 PHOTO COUPLER TLP421F (D4-GR)
0 PH602 6-600-438-01 PHOTO COUPLER TLP421F (D4-GR)
< TRANSISTOR >
0 Q11 6-551-319-01 FET 2SK3563 (LB2SONY)
0 Q12 6-551-319-01 FET 2SK3563 (LB2SONY)
0 Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q650 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q652 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
0 R2 1-219-512-11 METAL 2.2M 5% 1/2W F
0 R3 1-219-759-11 METAL 1M 5% 1/2W F
(SPZ70: E2, E51)
0 R4 1-219-759-11 METAL 1M 5% 1/2W F
(SPZ70: E2, E51)
0 R10 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
(SPZ70)
0 R10 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
(SPZ50)
0 R11 1-216-864-11 SHORT CHIP 0
0 R12 1-245-502-31 METAL 4.7M 2% 1/4W F
0 R13 1-245-502-31 METAL 4.7M 2% 1/4W F
0 R14 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
0 R15 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
(SPZ50)
0 R15 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
(SPZ70)
0 R16 1-218-823-11 METAL CHIP 100 0.5% 1/10W
0 R17 1-211-989-11 METAL CHIP 68 0.5% 1/10W
0 R18 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R20 1-216-833-11 METAL CHIP 10K 5% 1/10WF
0 R22 1-249-417-11 CARBON 1K 5% 1/4W F
0 R23 1-219-984-51 METAL 0.1 2% 2W F
0 R24 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R25 1-247-694-11 CARBON 33 5% 1/4W F
0 R27 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R29 1-216-797-11 METAL CHIP 10 5% 1/10W
R32 1-216-821-11 METAL CHIP 1K 5% 1/10W
R33 1-216-817-11 METAL CHIP 470 5% 1/10W
R41 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R603 1-216-852-11 METAL CHIP 390K 5% 1/10WF
0 R604 1-249-401-11 CARBON 47 5% 1/4W
POWER
Ver. 1.3
Note: Refer to the Servicing Notes “NOTE OF REPLACING MAIN
BOARD, IC1301 (MAIN BOARD), C25 (POWER BOARD)
OR POWER BOARD” (page 4), when you exchange the C25.
