Sony HCD-TZ100 - Case; Loading Panel

HCD-TZ100/TZ200/TZ300
7
Note: Follow the disassembly procedure in the numerical order given.
2-1. CASE
2-2. LOADING PANEL
1 screw
(case 3 TP2)
2 screw
(case 3 TP2)
3 five screws
(+BV3 (3-CR))
4 case
tray
1
2
3 loading panel
