Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
85
HCD-VX555/VX555J
MISCELLANEOUS
**************
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-690-589-31 WIRE (FLAT TYPE) (13 CORE)
0108 1-575-653-11 CORD, POWER (VX555J:JE)
0108 1-777-071-51 CORD, POWER (EXCEPT VX555J:JE)
0109 1-569-008-21 ADAPTOR, CONVERSION
155 1-454-887-11 PLUNGER
359 1-791-983-11 WIRE (FLAT TYPE) (8 CORE)
387 1-757-421-11 WIRE (FLAT TYPE) (25 CORE)
406 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
HP901 A-2004-765-A BASE (A) ASSY, HEAD
HRPE901A-2004-766-A BASE (B) ASSY, HEAD
M721 1-541-632-11 MOTOR, DC
M901 X-3378-246-1 MOTOR ASSY (CAPSTAN)
M961 1-763-072-11 FAN, D.C.
PM901 1-454-887-11 PLUNGER
PM902 1-454-887-11 PLUNGER
0T910 1-435-861-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-627-853-28 SCREW, PRECISION +P 2X3 TYPE3
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
