63
#2
#2
#4
#6
#2
#6
109
108
103
107
106
101
102
104
105
not supplied
not supplied
8-3. MAIN BOARD SECTION
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
102 A-4428-515-A MAIN BOARD, COMPLETE(SP,MY)
102 A-4473-072-A MAIN BOARD, COMPLETE(EA)
* 103 4-988-533-01 HOLDER, PWB
104 1-690-589-31 WIRE (FLAT TYPE) (13 CORE)
105 A-4428-511-A TRANS BOARD, COMPLETE
106 3-703-244-00 BUSHING (FBS001), CORD
107 A-4428-509-A POWER AMP BOARD, COMPLETE
0108 1-777-071-21 CORD, POWER
0109 1-785-504-11 ADAPTOR, CONVERSION
