8-6. BASE UNIT SECTION (BU-K2BD37A)
252
254
253
251
Ref. No. Part No. Description Remark
0251 8-820-116-01 OPTICAL PICK-UP BLOCK KSM-213DAP/Z-NP
252 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
253 A-4725-003-A BD BOARD, COMPLETE
254 4-951-620-01 SCREW (2.6X8), +BVTP
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
