79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
VIDEO
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-413-11 CARBON 470 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
R508 1-219-718-11 METAL 0.1 10% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
R510 1-219-718-11 METAL 0.1 10% 5W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-247-863-91 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-441-11 CARBON 100K 5% 1/4W
R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
R558 1-219-718-11 METAL 0.1 10% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
R560 1-219-718-11 METAL 0.1 10% 5W
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
R941 1-216-478-11 METAL OXIDE 390 5% 3W
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W F
R944 1-247-791-91 CARBON 22 5% 1/4W
R980 1-249-429-11 CARBON 10K 5% 1/4W
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
**************************************************************
1-675-911-11 SENSOR BOARD
**************
< CAPACITOR >
C712 1-164-159-21 CERAMIC 0.1uF 50V
< IC >
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-247-815-91 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
**************************************************************
A-4428-511-A TRANS BOARD, COMPLETE
**********************
1-533-293-31 FUSE HOLDER
< CONNECTOR >
CN975 1-564-321-00 PIN, CONNECTOR 2P
* CN977 1-564-524-11 PLUG, CONNECTOR 9P
* CN978 1-564-214-11 PIN, CONNECTOR (B3PS-VH) 3P
< FUSE >
0F971 1-532-325-00 FUSE T6.3AL 250V
0F972 1-532-350-00 FUSE 4A/250V
0F973 1-532-350-00 FUSE 4A/250V
0F974 1-532-325-00 FUSE T6.3AL 250V
0F975 1-532-325-00 FUSE T6.3AL 250V
< RESISTOR >
0R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
< SWITCH >
0S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
< TRANSFORMER >
0T971 1-435-323-11 POWER TRANSFORMER (EA)
0T971 1-435-325-11 POWER TRANSFORMER (SP,MY)
**************************************************************
A-4724-973-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C304 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C305 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C306 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C307 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
