81
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
L513 1-469-145-21 FERRITE 0uH
< TRANSISTOR >
Q501 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q502 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q531 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R302 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R303 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R306 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R308 1-216-073-00 METAL CHIP 10K 5% 1/10W
R309 1-216-073-00 METAL CHIP 10K 5% 1/10W
R310 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R311 1-216-029-00 METAL CHIP 150 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R313 1-216-073-00 METAL CHIP 10K 5% 1/10W
R314 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R315 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R316 1-216-022-00 METAL CHIP 75 5% 1/10W
R317 1-216-022-00 METAL CHIP 75 5% 1/10W
R318 1-216-295-91 SHORT 0
R319 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R320 1-216-295-91 SHORT 0
R403 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R404 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R501 1-216-025-91 RES-CHIP 100 5% 1/10W
R502 1-216-025-91 RES-CHIP 100 5% 1/10W
R503 1-216-025-91 RES-CHIP 100 5% 1/10W
R504 1-216-025-91 RES-CHIP 100 5% 1/10W
R505 1-216-025-91 RES-CHIP 100 5% 1/10W
R506 1-216-025-91 RES-CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-073-00 METAL CHIP 10K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-91 RES-CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-025-91 RES-CHIP 100 5% 1/10W
R531 1-216-025-91 RES-CHIP 100 5% 1/10W
R532 1-216-295-91 SHORT 0
R533 1-216-295-91 SHORT 0
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-91 RES-CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R539 1-216-295-91 SHORT 0
R540 1-216-295-91 SHORT 0
R542 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES-CHIP 100 5% 1/10W
R546 1-216-049-91 RES-CHIP 1K 5% 1/10W
R548 1-216-049-91 RES-CHIP 1K 5% 1/10W
R549 1-216-025-91 RES-CHIP 100 5% 1/10W
R550 1-216-025-91 RES-CHIP 100 5% 1/10W
R551 1-216-025-91 RES-CHIP 100 5% 1/10W
R552 1-216-025-91 RES-CHIP 100 5% 1/10W
R555 1-216-121-91 RES-CHIP 1M 5% 1/10W
R556 1-216-025-91 RES-CHIP 100 5% 1/10W
R557 1-216-025-91 RES-CHIP 100 5% 1/10W
R560 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R561 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R562 1-216-073-00 METAL CHIP 10K 5% 1/10W
R563 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC 10MHz
X503 1-767-519-11 VIBRATOR, CRYSTAL 27MHz
**************************************************************
MISCELLANEOUS
***************
11 1-792-246-11 WIRE (FLAT TYPE) (23 CORE)
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-769-987-11 WIRE (FLAT TYPE) (13 CORE)
0108 1-777-071-21 CORD, POWER
0109 1-785-504-11 ADAPTOR, CONVERSION
209 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
216 1-471-035-11 MAGNET ASSY
0251 8-820-116-01 OPTICAL PICK-UP BLOCK KSM-213DAP/Z-NP
252 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
M721 A-4672-826-A MOTOR ASSY
M961 1-763-072-11 FAN, DC
FL601 1-517-928-11 INDICATOR TUBE, FLUORESCENT
**************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
#7 7-685-781-09 SCREW +PTT 2X4 (S)
VIDEO
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
