HCD-WZ88D
Note:
F
ollo
w the disassembly procedure in the numerical order giv
en.
3-2.
CASE
3-3.
FRONT P
ANEL ASSY
1
three screws
(+BVTP 3
×
8)
2
two screws
(case 3 TP2)
4
case
3
two screws
(case 3 TP2)
0
front panel
section
4
connector
(CN109)
5
wire (flat type)
(23 core) (CN109)
8
three screws
(+BV 3
×
6)
2
screw
(+BVTP 3
×
8)
1
screw
(+BVTP 3
×
8)
6
screw
(+BV 3)
3
ear
th wire
7
ear
th wire
9
7
claw
9
11
