HCD-WZ88D
HCD-WZ88D
5-17. PRINTED WIRING BOARDS – VIDEO/MIC/VR/MS-203 SECTION –
• See page 21 for Circuit Boards Location.
:Uses unleaded solder.
IC801
IC702
IC701
C Y
G G
REGULATOR
BOARD
NO505
(Page 37)
M
DMB10
BOARD
CN202
(Page 26)
E
DMB10
BOARD
CN301
(Page 26)
C
COMPONENT
VIDEO OUT
E
P / C
RR
P / C
BB
Y
VIDEO OUT
S VIDEO OUT
MIC LEVELECHO LEVEL
MIC 2 MIC 1
MAIN BOARD
NO808
(Page 32)
J
MAIN BOARD
NO807
(Page 32)
I
(CHASSIS)
PHONES
M
CN001
1-861-327-
12,21
S001
(CHUCK/TRAY DETECT)
M203
(LOADING)
MS-203 BOARD
+
-
mm
i
12
A
B
C
D
E
F
34567 9
8
• Semiconductor
Location
Ref. No. Location
D702 E-7
D703 E-5
D704 E-5
D705 F-9
D706 F-9
IC701 E-6
IC702 F-9
IC801 C-3
Q800 C-1
