15
HCD-ZX80D/ZX100D
3-14. SENSOR BOARD
2 t ray
3 b elt (table)
5 p ulley (table)
8 s crew
(BTTP (M2.6))
0 SENSOR board
7 g ear (geneva)
9 connector
(
CN731)
1 floating screw
(PTPWH M2.6)
6 floating screw
(PTPWH M2.6)
4 floating screw
(PTPWH M2.6)
3-15. MOTOR (TB) BOARD
6 Remove the two solderings of motor.
8 MOTOR (TB) board
7 t able motor assy (M741)
5 two screws
(BTTP (M2.6))
4
3
wire (flat type) (5 core) (CN742)
1 stopper
2 stopper
