Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
147
HCD-FLX9W
MB
C0007 1-162-286-31 CERAMIC 220PF 10% 50V
C0008 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN0004 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
CN0005 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN0007 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D0005 8-719-991-33 DIODE 1SS133T-77
D0006 8-719-991-33 DIODE 1SS133T-77
D0007 8-719-991-33 DIODE 1SS133T-77
D0008 8-719-991-33 DIODE 1SS133T-77
D0009 8-719-991-33 DIODE 1SS133T-77
D0010 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* EP0002 1-537-738-21 TERMINAL, EARTH
*************************************************************
1-683-896-11 IN/MIDIN SW BOARD
*****************
< CONNECTOR >
* CN710 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S703 1-771-218-11 SWITCH, MICRO (MIDIN)
S704 1-771-218-11 SWITCH, MICRO (IN)
*************************************************************
1-683-897-11 INIT/COUNT SW BOARD
*******************
< SWITCH >
S705 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY) (INIT)
S706 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY) (COUNT)
*************************************************************
1-683-902-11 LOADING MOTOR BOARD
*********************
< CAPACITOR >
C703 1-162-306-11 CERAMIC 0.01uF 20% 16V
C704 1-126-964-11 ELECT 10uF 20% 50V
C712 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN713 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D702 8-719-109-85 DIODE RD5.1ESB2
< IC >
IC702 8-759-598-69 IC BA6956AN
< RESISTOR >
R703 1-249-411-11 CARBON 330 5% 1/4W
R704 1-249-401-11 CARBON 47 5% 1/4W
*************************************************************
A-1071-896-A MB BOARD, COMPLETE (EXCEPT TH)
A-1072-459-A MB BOARD, COMPLETE (TH)
*********
< SHORT/CAPACITOR >
C201 1-218-990-11 SHORT CHIP 0
C202 1-218-990-11 SHORT CHIP 0
C203 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C204 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C205 1-218-990-11 SHORT CHIP 0
C212 1-126-209-11 ELECT CHIP 100uF 20% 4V
C213 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C214 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C215 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C216 1-218-990-11 SHORT CHIP 0
C217 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C218 1-218-990-11 SHORT CHIP 0
C219 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C225 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C226 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C228 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C229 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C230 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C231 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C232 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C233 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C234 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C235 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C236 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C237 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C238 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C239 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C240 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C241 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C242 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C243 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C244 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C245 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C246 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C247 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C248 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C249 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C250 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C251 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C252 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C253 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C254 1-117-370-11 CERAMIC CHIP 10uF 10V
C255 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C256 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C257 1-117-370-11 CERAMIC CHIP 10uF 10V
C258 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C259 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C260 1-164-947-11 CERAMIC CHIP 0.01uF 50V
IN/MIDIN SWI/F INIT/COUNT SW LOADING MOTOR
