HCD-FLX9W
9191
HCD-FLX9W
IC601 qs (MCLK2)
500 mV/DIV, 50 µ s/DIV
ys
IC601 qf (SCKOUT)
yd
IC601 ql (LRCK0)
yf
IC601 w; (BCK0)
ya
500 mV/DIV, 50 µ s/DIV
500 mV/DIV, 10 µ s/DIV
500 mV/DIV, 200 ns/DIV
– DSP Board –
yg
IC611 qd (LRCK)
500 mV/DIV, 10 µ s/DIV
yh
IC611 qf (BCK)
500 mV/DIV, 200 ns/DIV
IC611 qh (SYSCK)
500 mV/DIV, 50 ns/DIV
yk
IC603 wk (XOUT)
yj
500 mV/DIV, 50 ns/DIV
74 µ s
3.8 Vp-
p
82 ns
3.5 Vp-
p
20.8 µ s
3.4 Vp-
p
326 ns
3.3 Vp-
p
20.8 µ s
3.5 Vp-
p
326 ns
3.2 Vp-
p
82 ns
3.5 Vp-
p
– SP RELAY Board –
Q4, Q5 (Base)
(REC mode)
500 mV/DIV, 5 µ s/DIV
rs
Q4, Q5 (Collector)
(REC mode)
rd
Q4, Q5 (Emitter)
(REC mode)
ra
2 V/DIV, 5 µ s/DIV
100 mV/DIV, 5 µ s/DIV
81 µ s
3.6 Vp-
p
2.1 Vp-p
12.1
µ s
12.1 µ s
10.8 Vp-
p
12.1 µ s
0.4 Vp-
p
– MC Board –
IC101 qa (XC-OUT)
500 mV/DIV, 10 µ s/DIV
ts
IC101 qd (X-OUT)
ta
500 mV/DIV, 20 µ s/DIV
30.6 µ s
2.6 Vp-
p
62.8 µ s
1.9 Vp-
p
– GC Board –
IC201 id (XO)
500 mV/DIV, 100 ns/DIV
ua
IC701 qk, ql (CR OUT)
(NTSC Color Bar)
500 mV/DIV, 20 µ s/DIV
is
IC701 wa, ws (CB OUT)
(NTSC Color Bar)
id
IC701 wf, wg (CY OUT),
wj, wk (Y OUT)
(NTSC Color Bar)
if
IC701 e;, ea (V OUT)
(NTSC Color Bar)
ia
500 mV/DIV, 20 µ s/DIV
500 mV/DIV, 20 µ s/DIV
500 mV/DIV, 20 µ s/DIV
– VIDEO Board –
ig
IC701 ed (C OUT)
(NTSC Color Bar)
200 mV/DIV, 20 µ s/DIV
250 ns
3.4 Vp-
p
H
1.2 Vp-
p
H
2.0 Vp-p
H
2.0 Vp-
p
H
1.4 Vp-p
H
1.4 Vp-p
– TX Board –
IC7002 tl (OSCO)
500 mV/DIV, 20 ns/DIV
oa
40.8 ns
2.6 Vp-
p
