Sony HDC1580 - SWITCH ASSIGN1 Menu; SWITCH ASSIGN2 Menu

33
Menu List
<CURSOR> 06
(U06)
CURSOR OFF ON, OFF display only if HDLA attached
BOX/CROSS BOX BOX, CROSS
H POSITION 50 0 to 99 display only if HDLA attached
V POSITION 50 0 to 99
WIDTH 50 0 to 99
HEIGHT 50 0 to 99
<VF OUT> 07
(U01)
VF OUT COLOR COLOR, Y, R, G, B,
(COLOR), (Y), (R), (G), (B),
(RET), (VF), (R+G), (R+B),
(G+B)
Settings in ( ): When HDLA
attached (cannot be
changed)
RET MIX VF OFF ON, OFF, (ON), (OFF) Settings in ( ): When HDLA
attached (cannot be
changed)
MIX DIRECTION RET MAIN, RET
MIX VF MODE Y-MIX Y-MIX, WIRE(W), WIRE(B)
MIX VF LEVEL 80% 0 to 80%
<SWITCH ASSIGN1> 08
(U08)
GAIN [L] 0 dB –3, 0, 3, 6, 9, 12 dB
[M] 6 dB –3, 0, 3, 6, 9, 12 dB
[H] 12 dB –3, 0, 3, 6, 9, 12 dB
ASSIGNABLE OFF OFF, RETURN1 SW,
RETURN2 SW, ENG, PROD,
VF DETAIL, MIX VF, 5600K,
FAN MAX, D.EXTENDER
When HDLA attached: OFF,
EXTENDER, 5600K, FAN
MAX, D.EXTENDER
Note
When you turn D.EXTENDER
ON or OFF, noise may be
generated. This is not a
malfunction.
RE.ROTATION STD STD, RVS Specify operation mode of the
MENU SEL knob.
STD: Clockwise rotation
moves , down or
increases values on the
menu screen.
RVS: Counterclockwise
rotation moves , down or
increases values on the
menu screen.
<SWITCH ASSIGN2> 09
(U09)
LENS VTR S/S RETURN2 SW OFF, RETURN1 SW,
RETURN2 SW, ENG, PROD
Assign a function to the VTR
START/STOP switch on the
mounted lens.
FRONT RET1 RETURN1 SW OFF, RETURN1 SW,
RETURN2 SW, ENG, PROD,
D.EXT
FRONT RET2 RETURN2 SW OFF, RETURN1 SW,
RETURN2 SW, ENG, PROD,
D.EXT
HANDLE SW1 RETURN1 SW OFF, RETURN1 SW,
RETURN2 SW, ENG, PROD,
ZOOM(T)
HANDLE SW2 INCOM1 OFF, RETURN1 SW,
RETURN2 SW, ENG, PROD,
ZOOM(W)
ZOOM SPEED 20 00 to 99
HKCT INCOM MIC ENG ENG, PROD Assign a function to the
INTERCOM MIC switch on the
HKC-T1500.
Page title No. Item Default Settings Remarks
