HDC1000/V2 (J, E)
Handle Assembly (HDC1400/1450/1500/1550/1580/1600)
No. Part No. SP Description
1601 ! A-1172-523-A s MOUNTED CIRCUIT BOARD, CN-2614B
1602 ! A-1099-125-A s MOUNTED CIRCUIT BOARD, SW-1237
1603 A-1128-447-A s HANDLE COVER ASSY
1604 A-8278-412-H s SHOE ASSY,VF
1605 X-3704-669-1 s HANDLE JIKUUKE PLATE ASSY
1606 1-963-914-11 s HARNESS, SUB (HANDLE SW)
1607 3-186-958-01 o NUT (VF), PLATE
1608 3-364-941-01 s SCREW (+B) (2.6X5),NYLOK
1609 3-612-822-01 s SPRING,COMPRESSION
1610 3-627-853-06 s SHOE,SLIDE
1611 3-628-261-01 s PIPE,VF SLIDE
1612 3-657-705-91 s BOLT (M4X8), HEXAGON HOLE
1613 3-673-018-11 s SCREW, BLIND (PLA)
1614 3-673-046-03 s LEVER, LOCK
1615 3-676-244-03 s COVER, SWITCH
1616 3-676-244-21 s COVER,SWITCH
1617 3-679-684-01 o REST,ARM
1618 3-679-702-01 o CUSHION,STOPPER(SLIDE ASSY)
1619 3-690-660-02 s LOCK,SCREW
1620 3-690-674-02 s KNOB,LOCK
1621 3-701-507-00 s SET-SCREW,HEX 3X5 ST
1622 3-710-024-02 s PACKING,VF
1623 3-711-765-01 s BOLT(M3),HEXAGON SOCKET(STEEL)
1624 3-729-076-11 s SCREW +B2X4 (STEEL)
1625 3-872-532-02 s HANDLE
1626 3-872-534-02 s WASHER02
1627 3-872-543-01 s SPRING,COMPRESSION(HANDLELOCK)
1628 3-872-563-01 s SHEET,HANDLE
1629 3-872-601-01 s TOGGLE SW CUSHION(C)
1630 3-872-609-02 s WASHER01
1631 3-872-615-01 s PLATE,VF SLIDE (Normal Type)
3-872-542-01 s PLATE,VF SLIDE(LONG) (Long Type)
1632 3-895-622-01 s RING (DIA. 5), O (NBR)
1634 * a 3-872-580-03 s LABEL (HANDLE)
7-623-208-22 s SPRING WASHER (3MM)
7-627-556-98 s SCREW,PRECISION +P 2.6X8 TYPE1
7-682-548-09 s SCREW +B 3X8
7-682-546-09 s SCREW +B 3X5
* a
* a Both labels are in one sheet.
