Sony HDR-UX3E - 5 Repair Parts List

NOTE
TO (2/2)
TO (2/2)
HDR-UX3E/UX5/UX5E/UX7/UX7E_L2
5. REPAIR PARTS LIST (1/2)
Link
Link
OVERALL SECTION FRONT PANEL BLOCK
MAIN BOARD SECTION
CABINET (L) SECTION
EVF BLOCK BT PANEL BLOCK
CABINET (R) BLOCK
(UX3E/UX5/UX5E)
CABINET (R) BLOCK
(UX7/UX7E)
EXPLODED VIEWS
EXPLODED VIEWS
NOTE: Characters A to Z of the electrical parts list indicate location of exploded views in which the desired part is shown.
LCD PANEL BLOCK
(UX3E/UX5/UX5E)
ABCD
EF H
I
G
LCD PANEL BLOCK
(UX7/UX7E)
J
LENS BLOCK
(UX3E/UX5/UX5E)
K
LENS BLOCK
(UX7/UX7E)
L
SHOE BLOCK ASSY
M
