5-2. ELECTRICAL PARTS LIST
HDR-UX3E/UX5/UX5E/UX7/UX7E_L2
• Refer to page 5-1 for mark 0.
注意
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
A-1239-345-A BL-004 BOARD, COMPLETE (UX7/UX7E)
A-1239-920-A BL-004 BOARD, COMPLETE (UX3E/UX5/UX5E)
***********************
< CAPACITOR >
C5901 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5902 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN5901 1-816-648-51 FFC/FPC CONNECTOR (LIF) 20P
* CN5902 1-817-560-71 CONNECTOR, FPC (ZIP) 21P
< DIODE >
* D5901 6-501-591-01 DIODE NESW007AT-T099 (EVF BACKLIGHT)
D5902 6-500-941-01 DIODE MAZS056008S0
A-1239-338-A CK-169 BOARD, COMPLETE (UX7/UX7E)
***********************
(BT8001 (lithium battery) is not included in CK-169 complete board.)
< BATTERY HOLDER >
0 BH8001 1-756-615-41 HOLDER, BATTERY (Note)
< BATTERY >
0 BT8001 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note)
< CONNECTOR >
CN8001 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
* CN8007 1-819-934-51 CONNECTOR, FPC (ZIF) 39P
* CN8008 1-817-563-71 CONNECTOR, FPC (ZIF) 31P
< DIODE >
D8004 8-719-083-91 DIODE EDZ TE61 6.8B
D8009 8-719-083-91 DIODE EDZ TE61 6.8B
D8010 8-719-083-91 DIODE EDZ TE61 6.8B
D8011 8-719-083-91 DIODE EDZ TE61 6.8B
< RESISTOR >
R8001 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R8002 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
< SWITCH >
S8001 1-771-138-82 SWITCH, KEY BOARD (RESET)
S8003 1-771-138-82 SWITCH, KEY BOARD (DISP/BATT INFO)
S8006 1-771-138-82 SWITCH, KEY BOARD (EASY)
S8007 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
S8008 1-771-138-82 SWITCH, KEY BOARD (PLAY)
BL-004 CK-169 CK-176
• Refer to page 5-1 for mark 0.
A-1239-339-A CK-176 BOARD, COMPLETE (UX3E/UX5/UX5E)
**********************
(BT8101 (lithium battery) is not included in CK-176 complete board.)
< BATTERY HOLDER >
0 BH8101 1-756-615-41 HOLDER, BATTERY (Note)
< BATTERY >
0 BT8101 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note)
< CONNECTOR >
CN8101 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
* CN8104 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
* CN8105 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
* CN8107 1-819-934-51 CONNECTOR, FPC (ZIF) 39P
* CN8109 1-816-650-51 FFC/FPC CONNECTOR (LIF) 24P
< DIODE >
D8104 8-719-083-91 DIODE EDZ TE61 6.8B
D8109 8-719-083-91 DIODE EDZ TE61 6.8B
D8110 8-719-083-91 DIODE EDZ TE61 6.8B
D8111 8-719-083-91 DIODE EDZ TE61 6.8B
< RESISTOR >
R8101 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R8102 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
< SWITCH >
S8101 1-771-138-82 SWITCH, KEY BOARD (RESET)
S8103 1-771-138-82 SWITCH, KEY BOARD (DISP/BATT INFO)
S8107 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
Electrical parts list of CM-076, CM-077 and
DH-042 boards are not shown.
Pages 5-16 to 5-19 are not shown.
Note: Replace the battery holder (BH8001, BH8101) together
when replacing the lithium battery (BT8001, BT8101) on
the CK-169 or CK-176 board. (The battery holder removed
once cannot be used again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note: CK-169またはCK-176基板のリチウム電池（BT8001，
BT8101）を交換する場合はバッテリホルダ（BH8001，
BH8101）も同時に新品に交換して下さい。（一度使用し
たバッテリホルダは再使用できません。）
部品取り付けの際は，先にバッテリホルダを取り付けてか
らリチウム電池を装着して下さい。
