5-20
Ref. No. Part No. Description Ref. No. Part No. Description
HDR-UX3E/UX5/UX5E/UX7/UX7E_L2
A-1239-344-A FP-454 FLEXIBLE BOARD, COMPLETE
(UX7/UX7E)
******************************
< IC >
IC001 6-705-011-01 IC AN48830B-NL
1-870-990-11 FP-535 FLEXIBLE BOARD
********************
(CN1001 and J1001 are not included in the FP-535 flexible board.)
< CONNECTOR >
CN1001 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P)
< JACK >
J1001 1-793-995-21 JACK, SUPER SMALL TYPE (REMOTE)
1-870-996-11 FP-541 FLEXIBLE BOARD
********************
(BH001 and J001 are not included in the FP-541 flexible board.)
< BATTERY TERMINAL >
0BH001 1-780-064-21 BATTERY TERMINAL BOARD
< CONNECTOR >
0J001 1-815-792-11 CONNECTOR, DC-IN (7.2V)
@ J001 1-815-792-11 CONNECTOR, DC-IN (7.2V)
A-1239-340-A FP-546 FLEXIBLE BOARD, COMPLETE
(UX3E/UX5/UX5E)
******************************
(S001 is not supplied, but this is included in the FP-546 flexible complete
board.)
< SWITCH >
S001 (Not supplied) SWITCH, DETECTION (SMD)
(PANEL REVERSE DETECT)
A-1239-328-A FP-580 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
* CN5801 1-819-696-21 CONNECTOR, HDMI (HDMI OUT)
< LINE FILTER >
* LF001 1-813-308-11 COMMON MODE CHOKE
* LF002 1-813-308-11 COMMON MODE CHOKE
* LF003 1-813-308-11 COMMON MODE CHOKE
* LF004 1-813-308-11 COMMON MODE CHOKE
A-1239-349-A FP-587 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
CN002 1-815-794-13 CONNECTOR (MULTIPLE) (A/V OUT)
A-1239-334-A FR-263 BOARD, COMPLETE (UX7/UX7E)
**********************
(D6502 is not supplied, but this is included in the FR-263 complete board.)
< CAPACITOR >
C6501 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6503 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6504 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6505 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN6501 1-820-133-51 CONNECTOR, FPC (ZIF) 23P
* CN6502 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
* CN6503 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
< DIODE >
D6502 (Not supplied) DIODE SML-512UWT86
(CAMERA RECORDING)
D6503 6-500-512-01 DIODE CL-330IRS-X-TU (NIGHTSHOT)
D6504 6-500-776-01 DIODE MAZW068H0LS0
< IC >
IC6501 6-600-163-01 IC RS-770
< TRANSISTOR >
Q6501 6-550-102-01 TRANSISTOR 2SC5663T2L
Q6502 6-550-384-01 TRANSISTOR DTC123JMT2L
< RESISTOR >
R6502 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6503 1-218-941-81 RES-CHIP 100 5% 1/16W
R6504 1-218-941-81 RES-CHIP 100 5% 1/16W
R6505 1-218-941-81 RES-CHIP 100 5% 1/16W
R6506 1-216-801-11 METAL CHIP 22 5% 1/10W
R6507 1-216-801-11 METAL CHIP 22 5% 1/10W
R6511 1-218-990-81 SHORT CHIP 0
R6513 1-218-941-81 RES-CHIP 100 5% 1/16W
R6520 1-218-990-81 SHORT CHIP 0
R6521 1-218-990-81 SHORT CHIP 0
A-1239-335-A FR-265 BOARD, COMPLETE (UX3E/UX5/UX5E)
**********************
(D9002 is not supplied, but this is included in the FR-265 complete board.)
< CAPACITOR >
C9001 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
* CN9001 1-820-133-51 CONNECTOR, FPC (ZIF) 23P
* CN9002 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
< DIODE >
D9002 (Not supplied) DIODE SML-512UWT86
(CAMERA RECORDING)
D9003 6-500-512-01 DIODE CL-330IRS-X-TU (NIGHTSHOT)
D9004 6-500-776-01 DIODE MAZW068H0LS0
FP-454 FP-535 FP-541 FP-546 FP-580 FP-587 FR-263 FR-265
• Refer to page 5-1 for mark 0.
