Appendix
Appendix A-5
AUDIO INPUT(AES/EBU) CH1/2, 3/4
BNC (2)
Complies with AES-3id-1995
TIME CODE IN XLR 3-pin, female (1)
0.5 to 18 Vp-p, 10 kΩ, balanced
Output connectors
HDSDI OUTPUT
BNC (3 including 1 for character
superimposition)
Serial digital (1.485 Gbits/s)
SMPTE 292M
SDTI OUTPUT BNC (2) (optional)
SMPTE 305M (SDTI)
COMPONENT VIDEO OUTPUT
BNC (3 for 1 set)
Y: 1.0 Vp-p, Sync negative
R–Y/B–Y: 0.7 Vp-p, 75 Ω, with
100% or 75% color bar selectable
COMPOSITE VIDEO OUTPUT
BNC (3 including 1 for character
superimposition)
1.0 Vp-p, 75 Ω, Sync negative
SDI OUTPUT BNC (3 including 1 for character
superimpositon)
Serial digital (270 Mbits/s)
SMPTE 259 M
AUDIO OUTPUT CH1/2/3/4
XLR 3-pin, male (4)
+4 dBm at 600 Ω load, low
impedance, balanced
CUE OUT XLR 3-pin, male (1)
+4 dBm at 600 Ω load, low
impedance, balanced
AUDIO OUTPUT (AES/EBU) CH1/2, 3/4, 5/6, 7/8
BNC (4)
Complies with AES-3id-1995
(CH1/2 and CH3/4 only for HDW-
2000)
MONITOR OUTPUT (L/R)
XLR 3-pin, male (2)
+4 dBm at 600 Ω load, low
impedance, balanced
TIME CODE OUT
XLR 3-pin, male (1)
2.2 Vp-p, low impedance, balanced
PHONES JM-60 stereo phone jack
–∞ to –12 dBu at 8 Ω load,
unbalanced
Remote connectors
CONTROL PANEL
10-pin (2), female
Front/rear selectable
REMOTE 1-IN(9P)
D-sub 9-pin, female
REMOTE 1-OUT(9P)
D-sub 9-pin, female
RS-232C D-sub 9-pin, male
VIDEO CONTROL(15P)
D-sub 15-pin, male (for optional
BVR-50/50P)
VIDEO CONTROL(9P)
D-sub 9-pin, female (for optional
HKDV-900)
REMOTE 2 PARALLEL I/O(50P)
50-pin, female
Memory card insertion slot
PCMCIA
Memory stick slot
Memory stick (8 to 128MB)
Accessories supplied
PSW 4 × 16 screws for rack mounting (4)
Operation Manual (1)
Installation Manual (1)
