Sony HVR-M10E - Page 79

HVR-M10C/M10E/M10J/M10N/M10P/M10U
4-79 4-80
4-3. PRINTED WIRING BOARDS
FP-230
For Schematic Diagram
• Refer to page 4-77 for printed wiring board.
1-865-799-
11
30
1
1
22
1
51
FP-230 FLEXIBLE BOARD (SIDE A)
1-865-799-
11
FP-230 FLEXIBLE BOARD (SIDE B)
• : Uses unleaded solder.
