64
Menu List
Chapter 4 Menu and Detailed Settings
<MULTI MATRIX>
P13
PHASE 0, 23, 45, 68, 90, 113, 135, 158,
180, 203, 225, 248, 270, 293,
315, 338
Selects an axis (angle) for which the multimatrix
adjustment to be made.
HUE -99 to 99 0
Independently sets the hue compensation for
16 axes.
SAT -99 to 99 0
Independently sets the saturation compensation
for 16 axes.
ALL CLEAR Execute by ENTER. The HUE and SAT values for all PHASE
settings are cleared.
GATE ON, OFF
, (SKN) Adds the gate signal to the image specified in
the PHASE settings.
(SKN): Displayed when SKIN GATE in SKIN
DETAIL is ON.
MATRIX ON, OFF
Sets the matrix function to on or off. All the
matrix functions can be activated or deactivated
at the same time, according to the individual
settings.
PRESET ON, OFF
Sets the preset matrix function to on or off.
SMPTE-240M, ITU-709
, SMPTE-
WIDE, NTSC, EBU, ITU-601, - -
Selects the preset matrix.
- - : When MATRIX is set to OFF (cannot be
changed)
USER ON, OFF
, - - Sets the user matrix function to on or off.
- - : When MATRIX is set to OFF (cannot be
changed)
MULTI ON, OFF
, - - Sets the multi matrix function to on or off. The
PHASE, HUE and SAT settings are available
when ON is selected.
- - : When MATRIX is set to OFF (cannot be
changed)
<SHUTTER>
P14
SHUTTER ON, OFF
59.94I, 59.94P: 1/100, 1/125,
1/250, 1/500, 1/1000,
1/2000 (sec)
50I, 50P: 1/60, 1/125, 1/250,
1/500, 1/1000, 1/2000 (sec)
Sets the shutter speed.
ECS FREQ 59.94I: 60.00
to 4300 Hz
59.94P: 59.96 to 4600 Hz
50I: 50.00
to 4700 Hz
50P: 50.03 to 4600 Hz
Sets the ECS frequency.
<NOISE SUP>
P15
NOISE SUP ON, OFF
Sets the noise suppressor function to on or off.
PAINT
Page title
Page No.
Item Settings Description
To Next Page
