– 8 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
* A-3662-892-A MAIN BOARD, COMPLETE (US)
* A-3679-659-A MAIN BOARD, COMPLETE
(Canadian, AEP , UK, E, AUS)
*********************
< CAP ACIT OR >
C1 1-102-945-00 CERAMIC 8.0PF ±0.5PF 50V
C2 1-101-004-00 CERAMIC 0.01uF 50V
C3 1-124-907-11 ELECT 10uF 20% 50V
C5 1-102-953-00 CERAMIC 18PF 5% 50V
C6 1-102-961-00 CERAMIC 27PF 5% 50V
C7 1-102-944-00 CERAMIC 7.0PF ±0.5PF 50V
C8 1-101-004-00 CERAMIC 0.01uF 50V
C9 1-126-963-11 ELECT 4.7uF 20% 50V
C10 1-101-004-00 CERAMIC 0.01uF 50V
C11 1-124-907-11 ELECT 10uF 20% 50V
C12 1-126-963-11 ELECT 4.7uF 20% 50V
C14 1-162-843-11 CERAMIC 0.022uF 10% 16V
C15 1-124-903-11 ELECT 1 uF 20% 5 0 V
C16 1-124-907-11 ELECT 10uF 20% 50V
C17 1-126-941-11 ELECT 470uF 20% 6.3V
C18 1-162-851-11 CERAMIC 0.1uF 10% 16V
C19 1-126-941-11 ELECT 470uF 20% 6.3V
C20 1-101-880-00 CERAMIC 47PF 5% 50V
< CERAMIC FIL TER >
CF1 1-577-072-11 FILTER, CERAMIC
CF2 1-760-144-61 FILTER, CERAMIC
CF3 1-760-144-61 FILTER, CERAMIC
< VARIABLE CAP A CIT OR >
CV1 1-141-529-11 CAP, VAR (TUNING)
CT1-4 1-141-529-11 CAP , VAR
< DIODE >
D1 8-719-911-19 DIODE 1SS119
< IC >
IC1 8-752-055-05 IC CXA1019S
< JACK >
J1 1-770-666-11 JACK ( @)
< COIL >
L1 1-501-770-11 ANTENNA, FERRITE-ROD (AM)
L2 1-406-546-11 COIL, AIR-CORE (FM RF)
* L3 1-428-306-11 COIL, AIR-CORE (FM OSC)
L4 1-406-028-00 COIL, OSC (AM OSC)
< RESISTOR >
R1 1-249-422-11 CARBON 2.7K 5% 1/4W
R5 1-249-397-11 CARBON 22 5% 1/4W
R6 1-249-421-11 CARBON 2.2K 5% 1/4W
R7 1-249-433-11 CARBON 2 2 K 5% 1/4W
R8 1-249-427-11 CARBON 6.8K 5% 1/4W
(US)
< VARIABLE RESIST OR >
RV1 1-228-790-00 RES, VAR, CARBON 50K (V OLUME)
< SWITCH >
S1 1-762-356-11 SWITCH, SLIDE (FM/AM/OFF)
< TRANSFORMER >
T1 1-404-790-11 TRANSFORMER, IF (AM IF)
************************************************************
MISCELLANEOUS
***************
* 12 1-656-281-11 POSITIVE TERMINAL BOARD
ANT1 1-501-774-11 ANTENNA, TELESCOPIC (FM)
SP1 1-504-861-11 SPEAKER (9.2CM)
************************************************************
**************
HARD WARE LIST
**************
#1 7-623-508-01 LUG, 3
#2 7-685-647-79 SCREW +P 3X10 TYPE2 NON-SLIT
#3 7-685-649-79 SCREW +P 3X14 TYPE2 NON-SLIT
************************************************************
MAIN
