– 14 –
Ref. No. Part No. Description Remark
MAIN
ICF-403S
9-927-158-11
Sony Corporation
Personal Audio Company
99H0261-1
Printed in Japan © 1999.8
Published by General Engineering Dept.
L2 1-424-529-21 COIL (SW TRACKING)
* L3 1-422-320-11 COIL, AIR-CORE (FM TRACKING)
L4 1-422-131-00 COIL, FM OSCILLATION (FM FREQUENCY
COVERAGE) (EXCEPT EA)
L4 1-459-954-21 COIL (WITH CORE) (FM FREQUENCY
COVERAGE) (EA)
L5 1-406-092-31 COIL, OSC (MW) (MW FREQUENCY
COVERAGE)
L6 1-406-093-31 COIL, OSC (SW) (SW FREQUENCY
COVERAGE)
< TRANSISTOR >
Q1 8-729-027-53 TRANSISTOR DTC124TKA-T146
< RESISTOR >
R1 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
(EXCEPT EA)
R3 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R5 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R6 1-216-045-00 METAL CHIP 680 5% 1/10W
R9 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R10 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R11 1-216-017-91 RES,CHIP 47 5% 1/10W
R13 1-216-049-91 RES,CHIP 1K 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-241-555-11 RES, VAR, CARBON 50K (POWER/VOL)
< SWITCH >
S1 1-771-748-11 SWITCH, SLIDE (FM, MW, SW)
S2 1-552-370-00 SWITCH, SLIDE (TONE)
< TRANSFORMER >
T1 1-404-790-11 TRANSFORMER, IF (AM IF)
**************************************************************
MISCELLANEOUS
*************
* 52 1-674-032-11 RACK RETAINER BOARD
ANT1 1-501-222-81 ANTENNA, TELESCOPIC (FM, SW)
D3 8-719-069-94 LEDTLR124 (TUNE)
SP1 1-529-451-11 SPEAKER (7.7cm)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-867-127-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, SPANISH, DUTCH, ITALIAN,
PORTUGUESE) (AEP)
3-867-127-21 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH, POLISH, HUNGARIAN, RUSSIAN,
CHINESE, ARABIC) (7AEP,AUS,EA)
