Sony ICF-C111 - Transformer Section Parts

18
ICF-C111
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q201 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2
Q202 8-729-216-22 TRANSISTOR 2SA1162-G (E92,MX)
< RESISTOR >
R1 1-216-815-11 METAL CHIP 330 5% 1/16W
R2 1-216-805-11 METAL CHIP 47 5% 1/16W
R4 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R5 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R6 1-216-821-11 METAL CHIP 1K 5% 1/16W
R101 1-216-849-11 METAL CHIP 220K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-845-11 METAL CHIP 100K 5% 1/16W
R104 1-216-841-11 METAL CHIP 47K 5% 1/16W
R105 1-216-835-11 METAL CHIP 15K 5% 1/16W
R106 1-216-815-11 METAL CHIP 330 5% 1/16W
R107 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R204 1-216-801-11 METAL CHIP 22 5% 1/16W
R205 1-216-821-11 METAL CHIP 1K 5% 1/16W
R206 1-249-409-11 CARBON 220 5% 1/4W
R209 1-249-389-11 CARBON 4.7 5% 1/4W
R210 1-249-389-11 CARBON 4.7 5% 1/4W
R212 1-216-833-11 METAL CHIP 10K 5% 1/16W
R213 1-216-833-11 METAL CHIP 10K 5% 1/16W
R214 1-216-833-11 METAL CHIP 10K 5% 1/16W
< SWITCH >
S1 1-692-181-21 SWITCH, SLIDE (BAND)
S2 1-771-904-11 SWITCH, SLIDE (Function selector)
S3 1-692-014-11 SWITCH, KEYBOARD (TIME SET M)
S4 1-692-014-11 SWITCH, KEYBOARD (TIME SET H)
S5 1-692-014-11 SWITCH, KEYBOARD (ALARM)
S6 1-692-014-11 SWITCH, KEYBOARD (CLOCK)
S7 1-692-014-11 SWITCH, KEYBOARD (SLEEP)
S8 1-692-014-11 SWITCH, KEYBOARD (SNOOZE/SLEEP OFF)
< TRANSFORMER >
T1 1-435-399-11 TRANSFORMER, IF
< VARIABLE RESISTOR >
VR1 1-228-790-00 RES, VAR, CARBON 50K (VOLUME)
< CONNECTION CORD >
W703 1-757-686-11 CORD, CONNECTION (17 CORE)
*************************************************************
* 1-680-065-11 TRANSFORMER BOARD
********************
0 1-555-795-00 CORD, POWER (E13,SP)
0 1-769-339-22 CORD, POWER (E92,MX)
0 1-790-124-11 CORD, POWER (AR)
< IC LINK >
0 PS101 1-533-971-11 LINK, IC (200mA) (AR,E13,SP)
< TRANSFORMER >
0 T2 1-433-573-11 TRANSFORMER, POWER (E92,MX)
0 T2 1-433-574-21 TRANSFORMER, POWER (AR,E13,SP)
< TERMINAL >
* TLM1 1-535-771-11 TERMINAL (AR,E13,SP)
* TLM2 1-535-771-11 TERMINAL (AR,E13,SP)
*************************************************************
MISCELLANEOUS
***************
0 5 1-555-795-00 CORD, POWER (E13,SP)
0 5 1-769-339-22 CORD, POWER (E92,MX)
0 5 1-790-124-11 CORD, POWER (AR)
53 1-535-804-21 SNAP, BATTERY
SP1 1-529-456-11 SPEAKER (6.6cm)
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-227-320-01 SHEET (BLIND) (BLACK) (E92)
3-227-320-11 SHEET (BLIND) (WHITE) (E92,MX)
3-227-587-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
GERMAN,SPANISH,DUTCH,ITALIAN)
(AR,E13,E92,MX)
3-227-587-41 MANUAL, INSTRUCTION (ENGLISH,
SIMPLIFIED CHINESE,POLISH,CZECH,
HUNGARIAN,SLOVAKIAN) (SP)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
TRANSFORMERMAIN
