17
ICF-C111
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3052-458-A MAIN BOARD, COMPLETE (E13)
* A-3683-274-A MAIN BOARD, COMPLETE (E92,MX)
* A-3683-279-A MAIN BOARD, COMPLETE (AR,SP)
*********************
1-535-804-21 SNAP, BATTERY
1-754-135-11 ANTENNA (WIRE)
3-226-590-01 HOLDER (ANTENNA)
7-685-647-79 SCREW +P 3X10 TYPE2 NON-SLIT
< BPF >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-162-936-11 CERAMIC CHIP 5PF 0.25PF 50V
C2 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C3 1-164-405-11 CERAMIC CHIP 27PF 5% 50V
C5 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6 1-104-664-11 ELECT 47uF 20% 10V
C7 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C8 1-126-960-11 ELECT 1uF 20% 50V
C9 1-126-963-11 ELECT 4.7uF 20% 50V
C10 1-126-964-11 ELECT 10uF 20% 50V
C11 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C12 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C13 1-126-964-11 ELECT 10uF 20% 50V
C14 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C15 1-126-924-11 ELECT 330uF 20% 10V
C16 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C18 1-104-665-11 ELECT 100uF 20% 10V
C19 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C20 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C101 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C107 1-126-961-11 ELECT 2.2uF 20% 50V
C201 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C203 1-126-934-11 ELECT 220uF 20% 16V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-126-935-11 ELECT 470uF 20% 10V
C207 1-126-935-11 ELECT 470uF 20% 10V
C210 1-126-933-11 ELECT 100uF 20% 16V
< FILTER >
CF1 1-781-861-71 FILTER, CERAMIC (COMBINATION)
CF2 1-781-790-11 FILTER, AM CERAMIC
CF3 1-781-861-71 FILTER, CERAMIC (COMBINATION)
< CONNECTOR >
* CN701 1-568-272-11 SOCKET, CONNECTOR 6P
< VARIABLE CAPACITOR >
CT1-4 1-141-522-11 CAP, VAR
CV1 1-141-522-11 CAP, VAR (TUNING)
< DIODE >
D101 8-719-911-19 DIODE 1SS119-25
D201 8-719-911-19 DIODE 1SS119-25
D202 8-719-052-88 DIODE 1N4002
D203 8-719-911-19 DIODE 1SS119-25
D204 8-719-911-19 DIODE 1SS119-25
D205 8-719-911-19 DIODE 1SS119-25
< IC >
IC1 8-752-037-02 IC CXA1019S
IC101 8-759-821-46 IC LM8560N
< JUMPER RESISTOR >
JC101 1-216-864-11 SHORT 0 (AR,SP)
JC102 1-216-864-11 SHORT 0 (AR,E13,SP)
JC103 1-216-864-11 SHORT 0 (AR,E13,SP)
JC105 1-216-864-11 SHORT 0
< COIL >
L1 1-419-532-11 COIL, FERRITE-ROD ANTENNA (AM)
L2 1-419-533-11 COIL, OSCILLATION (AM)
* L3 1-422-320-11 COIL, AIR-CORE
L4 1-422-131-00 COIL, FM OSCILLATION
< DIODE >
LED101 8-749-016-86 LED SL-3998-78T (E92,MX)
LED101 8-749-016-87 LED SL-3998-79T (AR,E13,SP)
LED102 8-719-054-61 LED SLR-342VRTJ7 (ALARM)
< TRANSISTOR >
Q1 8-729-216-22 TRANSISTOR 2SA1162-G
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AR : Argentina model
E13 : AC 220 – 230 V area in E model
E92 : AC 120 V area in E model
MX : Mexican model
SP : Singapore model
MAIN
