Sony ICF-C112 - Page 18

18
ICF-C112
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< DIODE >
LED101 6-500-504-01 LED COG509T0A1
< TRANSISTOR >
Q1 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q301 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q302 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2
< RESISTOR >
R2 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3 1-216-801-11 METAL CHIP 22 5% 1/10W
R4 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9 1-216-805-11 METAL CHIP 47 5% 1/10W
R10 1-216-837-11 METAL CHIP 22K 5% 1/10W
R11 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R13 1-216-833-11 METAL CHIP 10K 5% 1/10W
R14 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R15 1-216-817-11 METAL CHIP 470 5% 1/10W
R101 1-216-805-11 METAL CHIP 47 5% 1/10W
R108 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-845-11 METAL CHIP 100K 5% 1/10W
R110 1-216-845-11 METAL CHIP 100K 5% 1/10W
R111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R112 1-216-845-11 METAL CHIP 100K 5% 1/10W
R113 1-216-845-11 METAL CHIP 100K 5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
R117 1-216-849-11 METAL CHIP 220K 5% 1/10W
R133 1-216-845-11 METAL CHIP 100K 5% 1/10W
R135 1-249-389-11 CARBON 4.7 5% 1/4W
R136 1-216-801-11 METAL CHIP 22 5% 1/10W
R137 1-249-389-11 CARBON 4.7 5% 1/4W
R303 1-247-807-31 CARBON 100 5% 1/4W
R305 1-216-821-11 METAL CHIP 1K 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-228-790-00 RES, VAR, CARBON 50K (VOLUME)
< SWITCH >
S1 1-692-181-21 SWITCH, SLIDE (BAND) (BLACK)
S1 1-692-181-51 SWITCH, SLIDE (BAND) (WHITE)
S101 1-771-904-11 SWITCH, SLIDE (Function Selector)
S103 1-771-550-11 SWITCH, TACTILE (ALARM)
S104 1-771-550-11 SWITCH, TACTILE (CLOCK)
S105 1-771-550-11 SWITCH, TACTILE (TIME SET M)
S106 1-771-550-11 SWITCH, TACTILE (TIME SET H)
S108 1-771-550-11 SWITCH, TACTILE (SLEEP)
S111 1-554-937-11 SWITCH, TACTILE (SNOOZE/SLEEP OFF)
< TRANSFORMER >
T1 1-435-399-21 TRANSFORMER, IF
*************************************************************
SWITCH BOARD
*************
< SWITCH >
S100 1-692-181-21 SWITCH, SLIDE (ALARM VOL) (BLACK)
S100 1-692-181-51 SWITCH, SLIDE (ALARM VOL) (WHITE)
*************************************************************
A-3347-348-A TRANSFORMER BOARD, COMPLETE
******************************
0 1-769-339-22 CORD, POWER
< TRANSFORMER >
0 T301 1-433-573-21 TRANSFORMER, POWER
*************************************************************
MISCELLANEOUS
***************
SP1 1-529-456-13 SPEAKER (6.6cm)
*************************************************************
ACCESSORIES
************
3-247-335-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
MAIN TRANSFORMERSWITCH
