ICF-C112
Note : This set can be disassemble according to the following sequence.
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. PANEL (FRONT)
3-1. PANEL (FRONT)
(Page 5)
SET
3-2. CABINET (UPPER) SINGLE ASSY
(Page 6)
3-3. MAIN BOARD SECTION
(Page 6)
3-4. MAIN BOARD, LED101, SWITCH BOARD
(Page 7)
1 P 2.6x8
2
3
panel (front)
claws
claws
