ICF-C112
3-2. CABINET (UPPER) SINGLE ASSY
3-3. MAIN BOARD SECTION
1
P 3x30
2
P 3x30
3
4
cabinet (upper) single ass
y
3
P 3x10
1
Removal the solders.
2
CN1
4
MAIN board section
