17
ICF-C112
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3347-218-A MAIN BOARD, COMPLETE (BLACK)
* A-3663-993-A MAIN BOARD, COMPLETE (WHITE)
*********************
1-535-804-71 SNAP, BATTERY
1-754-135-11 ANTENNA (WIRE)
3-226-590-01 HOLDER (ANTENNA)
7-685-647-79 SCREW +P 3X10 TYPE2 NON-SLIT
< BPF >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C2 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C3 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C4 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C6 1-162-934-11 CERAMIC CHIP 3PF 0.25PF 50V
C9 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C15 1-126-947-11 ELECT 47uF 20% 10V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C17 1-126-960-11 ELECT 1uF 20% 50V
C18 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C21 1-126-963-11 ELECT 4.7uF 20% 50V
C22 1-126-964-11 ELECT 10uF 20% 50V
C23 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C24 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C25 1-126-964-11 ELECT 10uF 20% 50V
C26 1-126-935-11 ELECT 470uF 20% 10V
C27 1-115-156-11 CERAMIC CHIP 1uF 10V
C28 1-115-156-11 CERAMIC CHIP 1uF 10V
C29 1-104-665-11 ELECT 100uF 20% 10V
C31 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C32 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C33 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C34 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C35 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C105 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C109 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C118 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C301 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C303 1-126-935-11 ELECT 470uF 20% 10V
C304 1-126-934-11 ELECT 220uF 20% 16V
C306 1-126-934-11 ELECT 220uF 20% 10V
< FILTER >
CF1 1-781-790-11 FILTER, AM CERAMIC
CF2 1-781-861-71 FILTER, CERAMIC (COMBINATION)
CF3 1-781-861-71 FILTER, CERAMIC (COMBINATION)
< CONNECTOR >
* CN1 1-568-270-11 SOCKET, CONNECTOR 4P
< VARIABLE CAPACITOR >
CT3-6 1-141-620-11 CAP, VAR
CV1 1-141-620-11 CAP, VAR (TUNING)
< DIODE >
D1 8-719-911-19 DIODE 1SS119-25
D2 8-719-911-19 DIODE 1SS119-25
D111 8-719-911-19 DIODE 1SS119-25
D112 8-719-911-19 DIODE 1SS119-25
D114 8-719-911-19 DIODE 1SS119-25
D301 8-719-052-88 DIODE 1N4002
D302 8-719-911-19 DIODE 1SS119-25
D304 8-719-911-19 DIODE 1SS119-25
< IC >
IC1 8-752-037-02 IC CXA1019S
IC101 8-759-821-46 IC LM8560N
< JUMPER RESISTOR >
JC1 1-216-864-11 METAL CHIP 0 5% 1/10W
JC103 1-216-864-11 METAL CHIP 0 5% 1/10W
JC105 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
* L1 1-422-320-11 COIL, AIR-CORE
L2 1-422-131-00 COIL, FM OSCILLATION
L3 1-419-533-21 COIL, OSCILLATION (AM)
L4 1-419-532-41 COIL, FERRITE-ROD ANTENNA (AM)
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
MAIN
To Next Page
