Sony ICF-C112 - 1 Servicing Notes; Cord Dressing (Power Cord); Pointer Alignment

3
ICF-C112
SECTION 1
SERVICING NOTES
1-1. CORD DRESSING
(POWER CORD)
1) Set the power cord as shown in the figure.
2) Mount the chassis with power cord retainer
board and screws (P 3 × 10).
Note: Tighten completely the screws (P 3 × 10).
1-2. POINTER ALIGNMENT
screw P 3x10
power cord retainer boar
d
power cord
6 P 3x10
4
3
1
pointer
2 knob (tuning)
5 MAIN board
chassis
