Ref. No. Part No. Description Remark
MAIN
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
R8 1-216-849-11 METAL CHIP 220K 5% 1/10W
R9 1-216-845-11 METAL CHIP 100K 5% 1/10W
R10 1-247-791-91 CARBON 22 5% 1/4W
R12 1-216-833-11 METAL CHIP 10K 5% 1/10W
R13 1-216-833-11 METAL CHIP 10K 5% 1/10W
R14 1-216-803-11 METAL CHIP 33 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-228-790-00 RES, VAR, CARBON 50K (VOLw)
< SWITCH >
S1 1-771-905-21 SWITCH, SLIDE (BAND)
S2 1-771-904-21 SWITCH, SLIDE
(OFF/RADIO ON/RADIO/BUZZER)
S3 1-554-937-11 SWITCH, TACTILE (ALARM)
S4 1-554-937-11 SWITCH, TACTILE (TIME SET M)
S5 1-554-937-11 SWITCH, TACTILE (TIME SET H)
S6 1-554-937-11 SWITCH, TACTILE (CLOCK)
S7 1-554-937-11 SWITCH, TACTILE (SLEEP)
S8 1-771-550-31 SWITCH, TACTILE (SNOOZE/SLEEP OFF)
< TRANSFORMER >
T1 1-435-399-21 TRANSFORMER, (AM IF)
< FLAT CABLE >
W1 1-535-804-71 SNAP, BATTERY
* W2 1-769-137-11 CORD, CONNECTION (16 CORE)
*****************************************************
MISCELLANEOUS
*************
7 1-535-771-31 TERMINAL
0 14 1-555-795-00 CORD, POWER (SP)
0 14 1-790-431-12 CORD, POWER (AUS)
D7 6-500-077-01 DIODE COG309T0A1 (AUS)
D7 6-500-078-01 DIODE COG309T0E1 (SP)
L1 1-419-532-41 COIL, FERRITE-ROD ANTENNA (MW)
SP1 1-529-456-13 SPEAKER (6.6cm)
0 T2 1-433-574-31 TRANSFORMER, POWER
W1 1-535-804-71 SNAP, BATTERY
* W2 1-769-137-11 CORD, CONNECTION (16CORE)
*****************************************************
ACCESSORIES
***********
3-248-484-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, SPANISH, DUTCH, SWEDISH,
ITALIAN, PORTUGUESE, FINNISH,
SIMPLIFIED CHINESE)
