– 17 –
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
AUS: Australian EA: Saudi Arabia
IT : Italian SP : Singapore
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
* A-3662-242-A MAIN BOARD, COMPLETE (C290L)
* A-3662-244-A MAIN BOARD, COMPLETE (C290: AUS)
* A-3662-246-A MAIN BOARD, COMPLETE (C290: AEP, SP)
* A-3662-247-A MAIN BOARD, COMPLETE (C290: IT)
* A-3662-248-A MAIN BOARD, COMPLETE (C290: UK)
* A-3662-801-A MAIN BOARD, COMPLETE (C290: EA)
* A-3679-648-A MAIN BOARD, COMPLETE (C290: E)
*********************
1-535-804-21 SNAP, BATTERY
* 3-905-767-01 PLATE, SHIELD (C290L)
3-919-271-01 HOLDER (ANTENNA) (C290: E)
3-922-610-01 HOLDER (ANTENNA) (C290: EXCEPT E/C290L)
7-621-770-87 SCREW +P 2.6X5 (C290: E)
< CAPACITOR >
C1 1-102-936-00 CERAMIC 3.0PF +-0.25PF 50V
(C290: EXCEPT E)
C1 1-102-951-00 CERAMIC 15PF 5% 50V
(C290L)
C2 1-102-951-00 CERAMIC 15PF 5% 50V
(C290: AUS, AEP, UK, SP/C290L)
C2 1-102-952-00 CERAMIC 16PF 5% 50V
(C290: E)
C2 1-102-958-00 CERAMIC 20PF 5% 50V
(C290: IT, EA)
C3 1-102-960-00 CERAMIC 24PF 5% 50V
(C290: AUS, AEP, UK, E, SP/C290L)
C3 1-102-961-00 CERAMIC 27PF 5% 50V
(C290: IT, EA)
C4 1-101-081-00 CERAMIC 130PF 5% 50V
(C290L)
C4 1-102-937-00 CERAMIC 4.0PF +-0.25PF 50V
(C290: EXCEPT E)
C5 1-101-081-00 CERAMIC 130PF 5% 50V
(C290: E)
C6 1-101-880-00 CERAMIC 47PF 5% 50V
C7 1-104-664-11 ELECT 47uF 20% 10V
C8 1-101-004-00 CERAMIC 0.01uF 50V
C9 1-126-963-11 ELECT 4.7uF 20% 50V
C10 1-101-004-00 CERAMIC 0.01uF 50V
C11 1-101-004-00 CERAMIC 0.01uF 50V
C12 1-101-004-00 CERAMIC 0.01uF 50V
C13 1-126-963-11 ELECT 4.7uF 20% 50V
C14 1-124-907-11 ELECT 10uF 20% 50V
C15 1-101-005-00 CERAMIC 22000PF 50V
(C290)
C15 1-162-847-11 CERAMIC 0.047uF 10% 16V
(C290L)
C16 1-124-903-11 ELECT 1uF 20% 50V
C17 1-104-664-11 ELECT 47uF 20% 10V
C18 1-162-851-11 CERAMIC 0.1uF 10% 16V
C19 1-162-851-11 CERAMIC 0.1uF 10% 16V
C20 1-126-968-11 ELECT 100uF 20% 6.3V
C21 1-161-049-00 CERAMIC 0.0068uF 10% 50V
(C290: E)
C21 1-162-837-11 CERAMIC 0.0068uF 10% 16V
(C290: EXCEPT E/C290L)
C22 1-101-004-00 CERAMIC 0.01uF 50V
C23 1-101-004-00 CERAMIC 0.01uF 50V
C24 1-101-004-00 CERAMIC 0.01uF 50V
C25 1-101-004-00 CERAMIC 0.01uF 50V
C26 1-126-934-11 ELECT 220uF 20% 16V
C27 1-124-472-11 ELECT 470uF 20% 10V
(C290: EXCEPT E/C290L)
C27 1-126-941-11 ELECT 470uF 20% 6.3V
(C290: E)
C28 1-124-471-00 ELECT 1000uF 20% 6.3V
(C290: E)
C28 1-126-926-11 ELECT 1000uF 20% 10V
(C290: EXCEPT E/C290L)
C29 1-101-004-00 CERAMIC 0.01uF 50V
C30 1-101-004-00 CERAMIC 0.01uF 50V
C31 1-126-961-11 ELECT 2.2uF 20% 50V
(C290L)
< FILTER >
CF1 1-577-072-11 FILTER, CERAMIC (C290)
CF1 1-578-677-11 FILTER, CRYSTAL (C290L)
CF2 1-760-144-61 FILTER, CERAMIC
CF3 1-760-144-61 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-769-137-11 CORD, CONNECTION (16 CORE)
< TRIMMER >
CT5 1-141-227-00 CAP, TRIMMER 20PF (C290L)
MAIN
When indicating parts by reference
number, please include the board.
To Next Page
