13
ICF-C490
SECTION 6
ELECTRICAL PARTS LIST
* 1-684-735-11 LED BOARD
**********
3-243-988-01 SPACER
< LED >
D201 6-500-033-01 LED TOL-50BHRBKEA-KS04 (ALARM RADIO)
D202 6-500-033-01 LED TOL-50BHRBKEA-KS04
(ALARM BUZZER)
**************************************************************
* A-3021-915-A MAIN BOARD, COMPLETE (SP)
* A-3021-923-A MAIN BOARD, COMPLETE (AUS)
*********************
3-239-974-01 HOLDER (FERRITE-ROD ANTENNA)
< CAPACITOR >
C1 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C2 1-164-405-11 CERAMIC CHIP 27PF 5% 50V
C3 1-162-936-11 CERAMIC CHIP 5PF 0.25PF 50V
C5 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C7 1-126-964-11 ELECT 10uF 20% 50V
C8 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-126-960-11 ELECT 1uF 20% 50V
C10 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C11 1-126-963-11 ELECT 4.7uF 20% 50V
C12 1-126-964-11 ELECT 10uF 20% 50V
C13 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C14 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C15 1-128-551-11 ELECT 22uF 20% 25V
C16 1-126-935-11 ELECT 470uF 20% 10V
C17 1-115-156-11 CERAMIC CHIP 1uF 10V
C18 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C19 1-104-665-11 ELECT 100uF 20% 10V
C20 1-126-934-11 ELECT 220uF 20% 10V
C21 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C103 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C109 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-126-933-11 ELECT 100uF 20% 16V
C112 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-126-960-11 ELECT 1uF 20% 50V
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C118 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C121 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< CERAMIC FILTER >
CF1 1-781-859-71 DISCRIMINATOR, CERAMIC
CF2 1-781-790-11 FILTER, AM CERAMIC
CF3 1-567-802-71 FILTER, CERAMIC
< VARIABLE CAPACITOR >
CV1 1-141-522-11 CAP, VAR (TUNING)
< DIODE >
D101 8-719-911-19 DIODE 1SS119-25
D102 8-719-911-19 DIODE 1SS119-25
D103 8-719-911-19 DIODE 1SS119-25
D104 8-719-911-19 DIODE 1SS119-25
D105 8-719-921-88 DIODE MTZJ-13B
D106 8-719-911-19 DIODE 1SS119-25
D107 8-719-911-19 DIODE 1SS119-25
D108 8-719-911-19 DIODE 1SS119-25
< IC >
IC1 8-752-037-02 IC CXA1019S
IC101 8-759-823-50 IC LM8562
< SHORT >
JC1 1-216-864-11 SHORT CHIP 0
JC2 1-216-864-11 SHORT CHIP 0
JC4 1-216-864-11 SHORT CHIP 0
JC5 1-216-864-11 SHORT CHIP 0
JC101 1-216-864-11 SHORT CHIP 0
JC102 1-216-864-11 SHORT CHIP 0
LED MAIN
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
•Abbreviation
AUS: Australian model
SP : Singapore model
To Next Page
