Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
47
ICF-CD543RM
R218 1-216-821-11 METAL CHIP 1K 5% 1/16W
R219 1-216-817-11 METAL CHIP 470 5% 1/16W
R220 1-216-853-11 METAL CHIP 470K 5% 1/16W
R221 1-216-849-11 METAL CHIP 220K 5% 1/16W
R222 1-216-833-11 METAL CHIP 10K 5% 1/16W
R231 1-216-821-11 METAL CHIP 1K 5% 1/16W
R232 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R251 1-216-833-11 METAL CHIP 10K 5% 1/16W
R271 1-216-821-11 METAL CHIP 1K 5% 1/16W
R272 1-216-833-11 METAL CHIP 10K 5% 1/16W
R273 1-216-849-11 METAL CHIP 220K 5% 1/16W
R275 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R276 1-216-813-11 METAL CHIP 220 5% 1/16W
R277 1-216-817-11 METAL CHIP 470 5% 1/16W
R278 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R279 1-216-853-11 METAL CHIP 470K 5% 1/16W
R280 1-216-849-11 METAL CHIP 220K 5% 1/16W
R301 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R302 1-216-837-11 METAL CHIP 22K 5% 1/16W
R303 1-216-817-11 METAL CHIP 470 5% 1/16W
R304 1-216-841-11 METAL CHIP 47K 5% 1/16W
R305 1-216-821-11 METAL CHIP 1K 5% 1/16W
R311 1-216-845-11 METAL CHIP 100K 5% 1/16W
R312 1-216-845-11 METAL CHIP 100K 5% 1/16W
R313 1-216-833-11 METAL CHIP 10K 5% 1/16W
R314 1-216-833-11 METAL CHIP 10K 5% 1/16W
R331 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R333 1-216-805-11 METAL CHIP 47 5% 1/16W
R351 1-216-864-11 METAL CHIP 0
R352 1-216-845-11 METAL CHIP 100K 5% 1/16W
R371 1-216-809-11 METAL CHIP 100 5% 1/16W
R372 1-216-864-11 METAL CHIP 0
R373 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R374 1-216-845-11 METAL CHIP 100K 5% 1/16W
R375 1-216-857-11 METAL CHIP 1M 5% 1/16W
R911 1-216-809-11 METAL CHIP 100 5% 1/16W
R912 1-216-849-11 METAL CHIP 220K 5% 1/16W
R913 1-216-845-11 METAL CHIP 100K 5% 1/16W
0R951 1-219-149-11 FUSIBLE 1 5% 1/4W F
R953 1-249-413-11 CARBON 470 5% 1/4W
0R954 1-219-149-11 FUSIBLE 1 5% 1/4W F
R956 1-249-413-11 CARBON 470 5% 1/4W
R957 1-216-809-11 METAL CHIP 100 5% 1/16W
R958 1-216-809-11 METAL CHIP 100 5% 1/16W
< VARIABLE RESISTOR >
RV1 1-241-767-21 RES, ADJ, CARBON 100K
RV2 1-238-599-11 RES, ADJ, CARBON 4.7K
< VIBRATOR >
X51 1-567-769-11 VIBRATOR, CRYSTAL (75kHz)
**************************************************************
* 1-684-056-11 RAY CATCHER BOARD
******************
< IC >
IC403 6-600-480-01 IC SPS-440-VP
**************************************************************
* A-3178-334-A RELAY BOARD, COMPLETE
**********************
< CAPACITOR >
C671 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C672 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C673 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C674 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C676 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C677 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C678 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN671 1-580-182-11 SOCKET, CONNECTOR 3P
CN672 1-774-112-11 SOCKET, CONNECTOR 15P
* CN673 1-784-736-11 CONNECTOR, FFC 14P
< DIODE >
D671 8-719-063-79 DIODE 1N4002B
< RESISTOR >
JC671 1-216-864-11 METAL CHIP 0
< TRANSISTOR >
Q671 8-729-028-99 TRANSISTOR DTC114YUA-T106
< RESISTOR >
R671 1-216-845-11 METAL CHIP 100K 5% 1/16W
R672 1-216-845-11 METAL CHIP 100K 5% 1/16W
R673 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R674 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R675 1-216-845-11 METAL CHIP 100K 5% 1/16W
R676 1-216-845-11 METAL CHIP 100K 5% 1/16W
R677 1-216-841-11 METAL CHIP 47K 5% 1/16W
R678 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
**************************************************************
* 1-684-054-11 SWITCH BOARD
*************
< CAPACITOR >
C691 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< RESISTOR >
R691 1-216-833-11 METAL CHIP 10K 5% 1/16W
< SWITCH >
S691 1-554-061-00 SWITCH, SLIDE (MEGA BASS)
**************************************************************
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN RAY CATCHER RELAY SWITCH
